Home > Products > Gold Equipment > High-efficiency mini gold dredger
High-efficiency mini gold dredger
- 2 Set / Sets per Month
- Qingdao
- T/T
- 2021 Hot newest small 350 1000m3 Cutter Suction Dredger
- Hot Newest Sand Suction Dredging Boat Dredger for Sale Engineers Available to Service Machinery Overseas Customized Provided MAP
- Sand Dredging Machine 2021 Hot Newest Small 12 Inch Cutter Suction Dredger Engineers Available to Service Machinery Overseas MAP
- 2018 Hot newest small 1000m3 Sand Cutter Suction Boat
- Customized small 12 Inch cutter suction river dredging equipment
- 2022 Hot Newest Small 1200m3 Cutter Suction Dredger Manufacturer Sand Pump Suction Dredger Sand Dredging High Gold Recovery Rate
Product Details
Condition: | New | Type: | Other, Gold panning vessel | Power Type: | Diesel |
Dredging Depth: | 7 m | Draught: | 2 inch | Place of Origin: | Shandong, China |
Brand Name: | Shandong Shuiwang | Model Number: | Selecting joint equipment | Dimension(L*W*H): | 118ft*19.7ft*6ft |
Weight: | 20-40 ton | Certification: | ISO9001/ZC | Warranty: | 1 year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
High-efficiency mini gold dredger
SW Gold Minging Equipment is a mining joint unit of construction on the engineering punt and floating on the water surface, which generally includes mining, washing, selecting, tthe tailings
abandon and power generation, water supply, power supply, sliding and other equipment.
SW Gold Mining Equipment is integrated with the features of advanced technology, reasonable structure, reliable operation and easy maintenance.
Many years o production practice proves that gold mining equipment have the characteristic of high mechanization degree, large production capacity, less investment and quick effect and so on.
C Components of gold mining equipment mponents of gold mining equipment
1. Mining system
2. Mine Selecting Equipment
3. The Abandoned Tailings System
4.Water supply and ore delivery system
5. The winch and gantry system
6.The hull and the hull facilities
7.The upper structure and operating cabinet
8. Anchor
9. Power System
10. Electronic Control System
Model | SW-50 | SW-100 | SW-200 |
Performance | |||
Dimension(L*W*H)(mm) | 7000*2000*3000 | 8300*2400*4700 | 9800*3000*5175 |
Processing capacity (t/h) | 30-50 | 100-150 | 200-300 |
Main Power | |||
Power(kw) | 24 | 50 | 75 |
Feeder hopper | |||
Size (L*W*H) | 2000*2200mm | 3000*2200mm | 3800*3000mm |
Gold chutes with carpet | |||
Size (W*L) | 1000*2000mm | 1000*6000mm | 1000*6000mm |
Quantity | 2 | 2 | 3 |
Water system | |||
Pump power(kw) | 7.5 | 22 | 30 |
ocessing of gold mining equipment
1. Screening and washing (trommel screen).
Wash the raw ore and remove the barren rocks and gravels.
2. Enriching (Gravity separation equipment).
The gravity separation equipment such as the centrifugal concentrator, spiral chute, jig machine, are always applied at this process to enrich the heavy minerals.
3. Roughing, scavenging, and cleaning.
Shaking table for concentration after the 2nd step.
4. Refinery.
Gold melting furnace smelt the gold sand into shape.
work site
product in factory
gold dredgers
fine gold
worksite
Shandong Shuiwang Environmental Protection Equipment Co., Ltd.are specialized in high-standard sand washing machinery, amphibious excavator,submersible sand pump,diesel and gas generator and other mechanical equipment.
We have a 17000 square meters production base,20 technical staff ,5 senior.The company have good relationship with Guangzhou university,Guangxi metallurgy institute and other university or institute ,have passed ISO9001.
With the principal “capability will tell,credibility will win”,Shandong Shuiwang Envirommental Protection Equipment Co.,Ltd strives to provide best sevice to customers,more and more qualified products to customers.
Shuiwang company can provide a complete package of spare parts, maintenance support,
equipment training programmes, operating advisory services and operators for hands-on instruction and commissioning.
1.Guarantee period: 1 year after the date of completion of unloading of the goods at the
port of destination.
2.After the warranty expires,our company promises that we will provide a pay-needed
maintenance service for life.
