Gold Suction Dreger
1. Hull: It is madeof two or three pontoons,which used for installing various equipment, including operating cabin, pump cabin, etc.
2. Mining system:It is madeof the dredging bucket, chain, underwater big arm, upper and lower quadranglewheel, active power, main reducer, main frame and other components. It is mainly used in surface mining operation and ore mining.
3. Mine Selecting Equipment: It is made up of sand trommel screen, gold washing machine, pump, gold selecting chute or centrifugal concentration machine, etc. It is used for the completion of orescreening,washing,conveying, selecting and other operations.
4. The Waste Tailings System: It is madeofconveyor belt, chute, motor, reducer, and it is used for discharging waste gravel and tailings.
5. The Lifting System: it is madeof gantry, arm lifting winch, anchor winch, sliding winch, etc.. It is used for lifting and falling underwater arm, mooring dredger ,etc.
6.Power System: diesel engine, electronic generator sets, distribution box. It is used for providing lighting and working electricity and so on for the entire dredger.
Gold dredger at the working site
TECHNICAL SPECIFICATION
Gold Suction Dredger | ||
No. |
Principal Particulars |
Dimensions/Instruction(Metric) |
1 |
Principal Dimensions |
|
|
Length (about) |
5.0m |
|
Breadth (about) |
2.2m |
|
Depth (about) |
1.1m |
|
Bottom Steel Plate Thickness |
4mm |
|
Shell Steel Plate Thickness |
3.5mm |
|
Deck Steel Plate Thickness(anti-skid plate) |
3mm |
|
U-bar model |
12#, 10#, 8# |
|
Angle steel |
6#, 5#, 4# |
|
Hull structrue |
Outer: steel plate; inner: welded angle steel and U-bar |
|
Sand output |
30cbm/hr |
|
Discharge distance |
30m |
|
Dredging depth |
5m |
Gold Chute and Panning Grass
PROFESSIONAL LOADING
CUSTOMERS VISITING OUR FACTONRY
