Sand Dredging Ship
Features
(1) Good design
Our dredgers are designed by senior engineer, who have specialized in shipbuilding and dredging work for many years. It guarantees that our dredgers are well-designed and of high-quality.
(2) Good processing
Every dredger is built by skilled workers and inspected strictly to assure its high quality.
(3) New highly effective cutter and reliable hydraulic system.
(4) Fully tested before delivery
(5) Standard spare parts available from stock
(6) Detachable Structure
The cutter suction dredgers are detachable, so it is easy to transport when delivering or moving from one working site to another.
Working principle
First the hydraulic cutter in the ladder dredges clay below water, then dredged sand moved by the rotated cutter mixes with water and form liquid medium.Then the sand liquid in the inner cutter blade and beside the marine pump suction functioned by the fluid power of sand pump, enters sand pump, meanwhile, get some energy,at last, it is discharged to the destination through discharge pipe.
4. The technical specification for reference
12/10HCSD-10 | ||
NO. | ITEMS | PARAMETERS |
1 | Slurry output (solid output) | 1800cbm/h (216-360cbm/h) |
2 | Max Dredging depth | 10m |
3 | Max discharge distance | 1000m |
4 | Suction/discharge | 450/400mm |
5 | Pump model | 12/10G-GH |
6 | Main engine | Weichai X6170Z, 456KW, 1500RPM |
7 | Auxiliary engine | Weichai WD615, 190KW, 1500RPM |
8 | Generator | 24kw,1500rpm |
9 | Cutter | Outer Diameter 1250mm, power 75kw |
The parameters are for reference only. we will adjust the specifation according to the geographical condition and your requests.
Our Service
1. Reply your enquiry in 24 working hours.
2. Experienced staffs answer all your question in professional and fluent English.
3. Customized design is available.
4. Exclusive and unique solution can be provided to our customers by our well-trained and professional engineers and staffs.
