Help CenterHydraulic Cutter Suction Dredger Desilting Complete Equipment
Related Products
-
Sand Dredging Ship for Municipal Facility ProjectUS$ 300,000 - 490,000MOQ: 1 Unit -
High Quality Gold Dredger For Sale & Cutter Suction Dredger In RiverUS$ 490,000 - 600,000MOQ: 1 Unit
-
Dredger Machinery Used for Sea/riverUS$ 490,000 - 600,000MOQ: 1 Unit
-
River Sand Dredging Machine With Low PriceUS$ 490,000 - 600,000MOQ: 1 Unit
-
Desilting Equipment for River and Lake Dredge for SaleUS$ 490,000 - 600,000MOQ: 1 Unit
Company Information: Qingzhou Xianke Mechanical Device Co., Ltd.
1. Located in Huanglou Town, Qingzhou, Weifang City, Shandong Provence
2. Established in 2010, a professional manufacturer and exporter of dredgers
3. One building for office staffs
well-equipped, clean and tidy offices, and available facilities,
the office consists of Design Department, Sales Department, Logistics Department
Four workshops
Occupies over 1500square maters
Skilled workers
Advanced equipment
5. Near to Qingdao Port
Product Description
1. Working conditions
1)Environment: the temperature no higher than 40 degrees Celsius in summer and not lower than -10 degrees Celsius in winter, the air humidity is no more than 40%, wind power does not exceed 6 in rivers.
2River requirements: sand ratio is no less than 60% (clay content is no more than 10%, scree content is no more than 15%, gravel content is no more than 15% )
3)The ship diesel engine should apply to the CIS countries grade use of fuel, oil.
4The ship is equipped with nighttime lighting system suitable for all weather conditions and working uninterrupted.
5)2-3 person operate every time.
6)The dredger is equipped with safety barriers.
2. Features
(1) Good design
Our dredgers are designed by senior engineer, who have specialized in shipbuilding and dredging work for many years. It guarantees that our dredgers are well-designed and of high-quality.
(2) Good processing
Every dredger is built by skilled workers and inspected strictly to assure its high quality.
(3) New highly effective cutter and reliable hydraulic system.
(4) Fully tested before delivery
(5) Standard spare parts available
(6) Detachable Structure
The cutter suction dredgers are detachable, so it is easy to transport when delivering or moving from one working site to another.
3. Working principle
First the hydraulic cutter in the ladder dredges clay below water, then dredged sand moved by the rotated cutter mixes with water and form liquid medium.Then the sand liquid in the inner cutter blade and beside the marine pump suction functioned by the fluid power of sand pump, enters sand pump, meanwhile, get some energy,at last, it is discharged to the destination through discharge pipe.
4. The technical specification for reference
14/12CSD-10 | ||
NO. | ITEMS | PARAMETERS |
1 | Slurry output (solid output) | 2200cbm/h (264-440cbm/h) |
2 | Max Dredging depth | 10m |
3 | Max discharge distance | 1500m |
4 | Suction/discharge | 500/450mm |
5 | Pump model | 14/12G-G |
6 | Main engine | Weichai X8170Z, 601KW, 1800RPM |
7 | Auxiliary engine | Weichai WD618, 240KW, 1500RPM |
8 | Generator | 24kw,1500rpm |
9 | Cutter | Outer Diameter 1550mm, power 110kw |
|
| |
The parameters are for reference only. we will adjust the specifation according to the geographical condition and your requests.
Our Service
1. Reply your enquiry in 24 working hours.
2. Experienced staffs answer all your question in professional and fluent English.
3. Customized design is available.
4. Exclusive and unique solution can be provided to our customers by our well-trained and professional engineers and staffs.
Picture Images
Could you kindly tell us the following?
1. ing capacity?
2. Dredger dredging depth?
3. Dredger discharge distance?
4. Clean material or a lot of trash ? Any big stone in there?
Based on the honest, mutual benefit and development, we warmly welcome new and old customers to visit our company and negotiate business.
Weide has always been waiting here for our further communication in this field;
Tel:+86 13280757625
Whats App: +86 13280757625
Skype: qingzhouambition
