gear motor for drive shading system in greenhouse,5.2rpm,400Nm,400v

Specifications

1. Compact structure,
2.easy installation, 3.reliable operation.

Introduction:

XTB Gear motor are developed for the drive systems of greenhouses and livestock houses.They used proved technology and specially improved limit switches.XTB Gear motor has outstanding reliability and competitive prices.





Gear motor Advantage:



1. Compact structure,easy installation,reliable operation and long life performance.

2. Install limit switch emergency limit switch for reducing failure impact.

3. Small sizes,light weight(<30kgs),reducing the difficulty of installation.

4. Low noise,low temperature and beautiful appearence.

5. Insulation: IP55.





Gear motor Specification:



No.	Type Model	Voltage(AC V)	Power(kw)	Speed(r/min)	Torque(N.m)
1	XWJ40-2.6	380,400,220,110	0.55	2.6	400
2	XWJ40-5.2	380,400,220,110	0.55	5.2	400
3	XWJ80-2.6	380,400,220,110	0.75	2.6	800
4	XWJ80-5.2	380,400,220,110	0.75	5.2	600
