Film Greenhouse for Vegetable Cultivation

Specifications

Vegetable film Greenhouse
Glass greenhouse
Agricultural greenhouse for sale
Modern appearance
Stable structure

 Vegetable film Greenhouse



Advantage;



Full range and customized of product



Ideal price-quality ratio



Satisfactory service from “A” to ”Z”



True quality guarantee





I)Venlo Glass greenhouse



-Commercial Greenhouses - agricultural greenhouse for flower/vegetable



1.Feature:

Modern appearance, stable structure, high intensity, light transmission over 90%, special suitable for those places with less sunshine.





 2.Structural Characteristics:



♦ Venlo structure,



♦  Well sealed aluminum gutter,



♦ Cover: float or tempered glass, fitted by special aluminum profile together with sealed band



♦  Span: 8M, 9.6M, 12M,



♦  Section: 4M, 4.5M, 5M



♦  Wind load: 0.5 KN/M2, Snow load: 0.4KN/M2, Max Tonnage:150/M3/H



♦ Ventilation: Single or double roof vents, controlled by the rack and pinion system



♦ Shading, heating, cooling, irrigation, hydroponics, and climate control systems can be installed if requested





Polycarbonate greenhouse Venlo



-Commercial Greenhouses - agricultural greenhouse for flower/vegetable



1.Feature:

Good heat retention, high intensity, easy assembly, energy saving, anti dew, strong impact resistance and long service life, etc





2.Structural Characteristics:



 ♦ Venlo structure or A shape structure



 ♦ span: 8m/9.6M/12M, bay size: 3.2M/ 4M, section :4M/ 4.5M;



 Gutter: 3-5.5M



♦ The frame works structure is assembled by prefabricated parts. All main parts are hot dipping galvanized after processing with zinc cover 275G/M2 in order to avoid any rust;



 ♦ Cover: 8mm polycarbonate panel, by special aluminum profiles together with sealed band



 ♦ Ventilation: single roof vents or double roof vents, controlled by rack and pinion system



 ♦ Aluminum sliding doors;



Multi span plastic film greenhouse



--European structure, multi span commercial film greenhouse for agriculture



1.Feature:

Modern appearance, special designing structure, high intensity, easy assembly, single film is suitable for tropic area while air-inflated film is suitable for frigid area.





2.Structural Characteristics:



♦ Gothic roof structure, span: 8M/9.6M section : 4M /5M;



♦ Gutter height:3-5M, top height:5.5-7.5M.



♦ The frame works structure is assembled by prefabricated parts. All main parts are hot dipping galvanized after processing with zinc cover 275G/M2 in order to avoid any rust.;



♦ Covering is 3 layers extruding film, the outer layer has the function of dustproof and the inner layer anti-dripping; UV block treatment



♦ Roof configuration: following options are available based on customers' needs:





Plastic film greenhouse



--economical multi span film greenhouse, no foundation needed, satisfy basic growing needs



 1. Features:

Simple structure, easy assembly, low cost, it's the best choice for planting by big area.



2.Structural Characteristics :



♦ Gothic structure,



♦ span: 6M/8M/9M, arches space: catering for different climate conditions;



♦ Top height: 3.5-4M.



♦ Covering is 3 layers extruding film, the outer layer has the function of dustproof and the inner layer anti-dripping; UV block treatment



♦ Roof configuration: following options are available based on different climate conditions:

-One side fixed roof vents;

-Double side roof vents by film rolling up machine.

-No vents



♦ Side ventilation(optional): by film rolling up machines or fixed vents covered by mesh.





Plastic film greenhouse



--single tunnel plastic greenhouse/ low cost film greenhouse/ plastic tunnel house



1.Features:



Simple structure, easy assembly, low cost, it is the best choice for planting by big area .



2.Structural Characteristics:



♦  Gothic structure, span: 6-9M, arches space: catering for different climate conditions;



♦ Top height: 3.5-4M;



♦ The frame works structure is assembled by prefabricated parts. All main parts are hot dipping galvanized after processing with zinc cover 275G/M2;



♦ Covering is 3 layers extruding film, the outer layer has the function of dustproof and the inner layer anti-dripping; UV block treatment;



♦ Roof configuration/ventilation: following options are available based on different climate conditions:



--One side fixed roof vents



--Double side roof vents by film rolling up machine



--No vents



♦ Side ventilation(optional): by film rolling up machine or no vents.



Please contact saleman  if you want more info
