Home > Industrial Equipment & Components > Ventilation Equipment > Blowers > 12 Inch Exhaust Fan Hydroponic Stainless Steel Inline Duct Fan

12 Inch Exhaust Fan Hydroponic Stainless Steel Inline Duct Fan

Name: 12 Inch Exhaust Fan Hydroponic Stainless Steel Inline Duct Fan
Brand: TIDESTAR
SKU: 141732880
Availability: InStock

Yongkang Tengrun Electronics Co., Ltd.

12 Inch Exhaust Fan Hydroponic Stainless Steel Inline Duct Fan thumbnail-1

12 Inch Exhaust Fan Hydroponic Stainless Steel Inline Duct Fan photo-1

Negotiable MOQ: 1000 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Electric Current Type:

Blade Material:

Plastic

Mounting:

Duct Fan

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

NINGBO

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Electric Current Type DC

Blade Material Plastic

Mounting Duct Fan

Place of Origin Zhejiang, China

Brand Name TIDESTAR

Model Number TD-NW

Power 65-380W

Voltage 120/230V

Air Volume 290~1900m³/h

Certification CE

12 Inch Exhaust Fan Hydroponic Stainless Steel Inline Duct Fan

Typical sizes available: Ø100; Ø125; Ø150; Ø160; Ø200; Ø250; Ø305,Ø315

Colour available: Black, White

It is used to transmit and strengthen the air flow inside a network of ventilation ducts.

The Plastic Inline Duct Fan is equipped with ball bearing and visible propeller with a protective grate. The installations can be mounted horizontally and vertically.

The propeller blades are directed backwards, ensuring higher pressure and work effciency.

The casing is made from Plastic (ABS) and the fan sat included fixings for a secure installation.

Accessories:It is possible to connect a variable speed controller, Providing the customer with variable airflow setting.

Specific technical parameter:

Model	Voltage	Frequency	Power	Rotate	Air Flow	Pressure
(HCEU)	(V )	(HZ)	(W)	(R/Min)	(M3/H)	(Pa)
Φ100mm	120 / 230	60 / 50	69	2590	350	360
Φ125mm	120 / 230	60 / 50	71	2535	440	390
Φ150mm	120 / 230	60 / 50	100	2350	610	430
Φ160mm	120 / 230	60 / 50	130	2580	700	475
Φ200mm	120 / 230	60 / 50	190	2150	1050	620
Φ250mm	120 / 230	60 / 50	195	2250	1200	635
Φ305mm	120 / 230	60 / 50	245	2450	1850	690
Φ315mm	120 / 230	60 / 50	250	2520	1900	720
