150cc ATV(utility Style,200cc,250cc Available)

Specifications

150cc ATV

1) Engine style: single cylinder, air-cooled, 4-stroke
2) Bore x stroke: 57.4 x 57.8 (mm x mm)
3) Lubrication: pressure / splash
4) Max. power: 7.0 / 7000±150 (Kw/r/min)
5) Max. torque: 8.8 / 5500±150 (N.m/r/min)
6) Ignition: C.D.I.
7) Starting type: electric
8) Oil consumption: ≤365g/kW
9) Clutch
10 )Transmission: CVT, can be made with reverse gear
11) Dimensions (L x W x H): 1,625 x 860 x 960mm
12) Tyre and rim: a) Front: 19 x 7-8 b) Rear: 18 x 9.50-8
13)  Brake style: a) Front: drum  b) Rear: disk
14) Absorber style:a) Front: independent hanging b) Rear: middle absorber
15) Oil tank capacity: 7.5L
16) Climbing ability: ≥25°
Outer packing:
    Packing dimensions (L x W x H): 1,485 x 835 x 780mm
                             N.W.: 125kg  G.W.: 145kg
