200CC Quad ATV

Specifications

NAME: ATV

MOD: ATV-033-200CC

Details product description:
1)Type:Single cylinder, water cooling,four stroke
2)Ignition mode:C.D.I
3)Compression proportion:9.0:1
4)Start mode:Electric
5)Fuel tank capacity:4L
6)Transmission mode:Chain
7)Transmission gear:R-N-1-2-3-4  Manual clutch
8)Driving mode:Rear wheel drive
9)Rating power:11.0kw/7500rpm
10)Max torque:14.5N.m/6500rpm
11)Min ground clearance :120mm
12)Max speed:≥70km/h
13)Battery:12V9Ah
14)Cylinder size:63×62mm
15)Engine oil:1300ml
16)Lubrication:Press splash
17Displacement:193.3ml
18)Front wheels:19× 7.00-8
19Rear wheels:18× 9.5-8
20)Break type (F/R):Drum/. disc
21)Front hanging:Double arm-swing
22)Rear hanging:Integral
23)Product dimensions:1760× 990×1130mm
24)Wheelbase:1170mm
25)Height of seats:750mm
26)Load capacity:130kg
27)Climbing degree:≥18°
28)The smallestturning semidiameter:2.6m

Out packing:
Carton dimensions:1495×840×845mm
N.W./G.W.:130/150kgs
Conveyance:
Qty/20 GP: 20 units
Qty/40 GP: 44 units
Qty/40 HQ: 66 units
