Specifications
90 days warranty and bottom price from the factory !Specification And Performance Parameters CR-Ⅱ
Type of petrol engine | 50type | 60 type | 80type |
Mode of engine | Single cylinder air cooling 2-stroke | ||
Bore & stroke | 40mmx38mm=48cm3 | 45mmx40mm=60cm3 | 50mmx40mm=70cm3 |
Ignition Mode | CDI | ||
Compression ratio | 6:01 | ||
Driving ratio | 18:01 | ||
Starting System | pedal | ||
Lub.Oil | oil for 2-stroke perol engine(or for 10w/40,10w/30) | ||
Mixing ratio of fuel and engine oil | 16:1 for new sets, 20:1 after running 500km | ||
Type of sparking plug | Z4C 16MMM | ||
Volume of oil consumption | 1.5L/100km | 2.0L/100km | 2.5L/100km |
Net weight of main set | 6.5kgs | 7.0kgs | 8.0kgs |
Type of clutch | Friction plate Dry | ||
Cooling mode | Natural air cooling | ||
Speed limitation | 30km/hour | 35km/hour | 38km/hour |
Power rotary speed | Rated power | Rated power | Rated power |
| 1.15kw/5000r/min | 1.5kw/5000r/min | 2.5kw/5000r/min |
| (1.6 HP/5000r/min) | (2HP/5000r/min) | (3HP/5000r/min) |
Max.Power | 1.6kw/6000r/min | 2kw/6000r/min | 3.5kw/6000r/min |
| (3HP/6000r/min) | (4-5HP/6000r/min) | (5-6HP/6000r/min) |
