Name: Digital Temperature Humidity Detector
Model:THD200
The THD200 is special for monitoring for strict indoor temperature and humidity control applications. It is an industrial class, high reliability, low-power consumption, high stability and high precision digital transducer.
The THD200 is used widely as a temperature and humidity measure of Laboratory, museum, warehouse, wareroom, storehouse, depot, depository, depositary, generator room, machine room, engine room, etc.
The THD200 with LCD, can be set temperature alarm threshold value, when the ambient temperature is lower than the Min. value or higher than the Max. value, the detector will be triggered and output one dry contact signal.
The THD200 with fire retardant shell, wall mounting makes it easy to install in fields.
Specifications:
Items | Specifications |
Rated Power Input | 12VDC |
Measurement Range | Temperature: -10~50°C; Humidity:0~100%RH |
Output Type | 2 Dry Contact(NO, Photoelectric isolated); 1 for temperature alarm, 1 for humidity alarm |
Precision | +/-0.5°C and +/-3% RH at 25°C,30~80%RH. |
Step | 1°C |
Non-Linear | <1% |
Power Consumption | <30mA; |
Installation Type | Wall-mounting |
Relative Humidity | 0~100%RH.; |
Operation Temperature | -20~70°C; |
Dimension | 86X86X30mm(HxWxD) |
Net Weight | 100g. |
