Tricycle KM175ZH-4B

Tricycle KM175ZH-4B thumbnail-1
Tricycle KM175ZH-4B photo-1
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Use For:
Cargo
Driving Type:
Motorized
Displacement:
151 - 200cc
Contact Supplier Request Quote Chat Now
Chongqing Sayin Imp & Exp Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Chongqing China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Use For Cargo
Driving Type Motorized
Displacement 151 - 200cc
Body Type Open
Place of Origin Chongqing, China
Model Number KM175ZH-4B

Specifications

Tricycle
Transmission mode: shaft/chain
Displacement: 175ml
Max.Power: 10.5KW /8000 r/min
Max.torque: 13.5N.m/6000 r/min

Tricycle
Engine 175CC
Type: Single-Cylinder,4-stroke, Air-cooling
Ignition mode: CDI
Compression proportion: 9.2:1
Start mode: Electric/kick
Transmission mode: shaft/chain
Displacement: 175ml
Max.Power: 10.5KW /8000 r/min
Max.torque: 13.5N.m/6000 r/min
Transmission: 5-forward and 1 Reverse
Cylinder size: 62×58mm
Engine oil: 0.9 L
Gas cylinder number: one
Chassis
Front wheels: 4.00-123.25-18
Rear wheels: 4.00-12
Break type (F/R): front hand brake,back kick brake
Front hanging: suspension
Rear hanging: Rocker Arm
Dimensions
Product dimensions : 3300×1380×1400mm
Carton dimensions: 1670×540×1290mm
Wheelbase: 1860mm
Min.ground clearance: 170mm
Max.speed 60km/h
seat Height: 820mm
ehicle weight: 350KG
Load capacity: 360KG
Fuel tank capacity: 17L
Min Fuel consumption 354g/km.h
Power source: 12V 24AH
Climbing degree: 11°
Min. turning radius: 4m
Parking trig: hand
Max. number of riders: 1
Others
20 GP 20
packing way:CKD
40GP 40
packing way:CKD
40HQ 55
packing way:CKD
Color: Red,green,blue,white and other
