KM125-28,2012 NEW MODLE 110&125CC CUB

Specifications

110cc CUB motorcycle(50cc,70cc 125cc engine optional)
Engine:4-Stroke,Single Cylinder Air Cooled

ENGINE:

Type: 125cc, 4-Stroke Single cylinder,Air Cooled

Transmission: 4-Speed, Auto Clutch

Compression: 9.1:1

Output, Max(Kw/Rpm): 5.2/8000

Torque, Max(N.M/Rpm): 7.2/5000

Ignition: CDI

Starting System: Electric/Kick

BorexStroke: 52.4mm x49.5mm



CHASSIS:

Suspension/Front:Hydraulic Spring Shock

Suspension/Rear:Hydraulic Spring Absorber,  Arm Swing

Brakes/Front:Disc

Brakes/Rear:drum

Tires/Front:2.50-17(P01)

Tires/Rear:80/100-14(P48)

Reserve:N/A

Drive Train:Chain



DIMENSIONS:

LxWxH:2055×690×1250mm

Wheelbase:1300mm

Seat Height:780mm

Min ground clearance:160mm

Net  Weight: 105kg

Max Load: 150kg

Climbing Ability: ≥15°

Fuel Tank Capacity: 5L

Top Speed: 85Km/h

Battery: 12V/5Ah



OTHERS:

COLOR: Red/Blue/Yellow/Green/Black

Fuel Type: Unleaded Gasoline With Octane No. 93 Or Higher

PACKING BOX SIZE: 1700mm×430mm×870mm

LOADING  QTY: 105units/40HQ, 51 units/40GP, 24 units/20GP,
