Specifications
ATV/Quad.buggy/Dirt.Bike/Pocket.Bike/Dune.Buggy/Go.Kart/Atv/Bicycle/Tricycle/Scooter/Electric Bike/All Terrain Vehicle/truck/ren
Specification
DIMENSIONS
Overall Length--------------------------------------------------------------------------------------------------3140mm
Overall Width -------------------------------------------------------------------------------------------------- 1850mm
Overall Height ------------------------------------------------------------------------------------------------- 1580mm
Wheelbase --------------------------------------------------------------------------------------------------------2450mm
Front Track ------------------------------------------------------------------------------------------------------ 1375mm
Rear Track --------------------------------------------------------------------------------------------------------1570mm
Ground Clearance ------------------------------------------------------------------------------------------------310mm
ENGINE
Type -------------------------------------------------------------------------------4 Cylinder,4-Strokes,water cooled
Bore x Stroke --------------------------------------------------------------------------------------------------72×66.5mm
Displacement ------------------------------------------------------------------------------------------------------1083mL
Compression ratio -------------------------------------------------------------------------------------------------9.5:1
Carburetor --------------------------------------------------------------------------------------- Electric Fuel Injection
Max Power ---------------------------------------------------------------------------------------------50KW/6000rpm
Maximum Torque ------------------------------------------------------------------------------90/3500-4000Nm/r/min
Fule consumption------------------------------------------------------------------------------------------6L/100km
Starting ----------------------------------------------------------------------------------------------------------- Electric
Ignition -------------------------------------------------------------------------------------------- Electric Fuel Injection
Lubrication -------------------------------------------------------------------------------------------- Force & Splash
Transmission ------------------------------------------------------------------------ Manual clutch, 5 shift/Reverse
Fuel type ------------------------------------------------------------------------------------------------ RQ93 (unleaded)
Engine oil ----------------------------------------------------------------------------------------------------- SAE-10W/30
Gear oil ----------------------------------------------------------------------------------------------------- GL-4 75W/90
CAPACITIES
Maximum load -----------------------------------------------------------------------------------------------------250kg
Fuel tank --------------------------------------------------------------------------------------------------------------- 30L
Engine oil ---------------------------------------------------------------------------------------------------------------3.5L
Gear oil ------------------------------------------------------------------------------------------------------------------2.0L
Starting ----------------------------------------------------------------------------------------------------------------≤15s
Climbing -------------------------------------------------------------------------------------------------------------- ≥25°
Battery ------------------------------------------------------------------------------------------------------------ 12V36Ah
Head Light -------------------------------------------------------------------------------------------------- 12V 55W/ 5W
Redirector Light -------------------------------------------------------------------------------------------------- 12V 5W
Tail Light -----------------------------------------------------------------------------------------------------12V 21W/ 5W
Horn---------------------------------------------------------------------------------------------------------------------12V3A
Fuse ------------------------------------------------------------------------------------------------------------------------30A
SPECIFICATIONS
Brake Track ----------------------------------------------------------------------------------------------- < 7m @40 km/h
Top speed -------------------------------------------------------------------- 100km/h (or limited as customers require)
CHASSIS
Front, Rear brake --------------------------------------------------------------- Hydraulic disc, right foot control
Front tire ------------------------------------------------------------------------------------------------------------ 27×8-14
Rear tire ------------------------------------------------------------------------------------------------------------ 27×11-14
Front Suspension --------------------------------------------------------------------------- Independent Dual A-Arm
Rear Suspension ---------------------------------------------------------------------------- Independent Suspension
Final Drive --------------------------------------------------------------------------------------------------- shaft driven
TIRE PRESSURE
Front ----------------------------------------------------------------------------------------------- 250kpa2.5kg/cm2 36psi
Rear ------------------------------------------------------------------------------------------------ 250kpa2.5kg/cm2 36psi
WEIGHT
Net Weight ------------------------------------------------------------------------------------------------------------666kg
G.W ---------------------------------------------------------------------------------------------------------------------700kg
Container quantity-----------------------------------------------------------------------20GP:4Units. 40HQ:12Units
Carton dimiensions----------------------------------------------------------------------2930 mm×1770mm×850mm
