Negotiable MOQ: 8 Units (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
500CC
Certificate:
EEC
Fuel:
Gas / Diesel
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo
Delivery Detail:
Delivery time depends on order quantity.
Type 500CC
Certificate EEC
Fuel Gas / Diesel
Transmission Type Automatic

Specifications

C.V.T Automatic clutch R/N/L/H.
4X4 and 4X2 swithchable, 4-wheel independent suspension

C.V.T  Automatic clutch R/N/L/H.
Water Cooling,Shaft drive.
4X4 and 4X2 swithchable, 4-wheel independent suspension.
Brake type:   F:dual disc brake;  R:dual disc brake.
Auto  Dump Bed by electromotion.
PACKING
unit packingCarton and steel frame
qty per unit packing1Pcs
unit packing: (LxWxH)2300X1300X1270mm
unit packing (G.W./N.W.)650KG/590KG
qty per export carton
export carton (LXWXH)2300X1300X1270mm

export carton (G.W./N.W.)650KG/590KG

units per 20"/40" 40"HQ
18PCS/40'HQ
minimum order qty
Bitmap Bitmap
 ENGINE :Displacement: 493ml/32.6HP (Limit 20.4HP for Europe)
               Cooling:  water
               Engine Type: CF moto  500cc (CF188)
               Fuel Capacity:22.0L
               Bore&stroke:  87.5*82mm
DRIVE:   Transmission:  C.V.T  Automatic clutch(R/N/L/H)
              Ignition type:  electric and recoil starter.
SUSPENSION :  Front:1036mm
                          Rear: 1040mm
SPEED: max net power ourput:70 km/h
BRAKE: Front/Rear: dual disc brake,
             Rear:dual disc brake.
             Parking brake
TIRE:  Front: 25×8-12  ; Rear: 25×10-12
DIMENSION:
                       Wheelbase: 1730mm
                       Ground Clearance:  1210mm
                       Net Weight: 550 KG
                       Maximum Load: 300 KG
