SEADOO

CRATE/IRON

Specifications

SEADOO OFICIAL , MADE IN CANADA , LEADER IN WATERCRAFT , STOCK IN EUROPE 2 YEARS WARRANTY

Specifications

Dimensions

Length ...........................................139" / 354 cm

Width ............................................48" / 122 cm

Height ...........................................45.9" / 116.6 cm

Weight (dry) ...................................GTX 215 : 855 lb. / 388 kg

GTX 155 : 825 lb. / 374 kg

Rider capacity ...............................3

Fuel capacity .................................15.9 US gal / 60 l

Storage capacity ...........................13.7 US gal / 52 l

Engine

Type ...............................................

GTX 215: 1503 SC Rotax® 4-TEC® engine*



GTX 155: 1503 NA Rotax 4-TEC engine

Intake system ................................GTX 215: Supercharged with intercooler,

60 mm throttle body

GTX 155: Naturally aspirated,

60 mm throttle body

Bore x stroke .................................100 mm x 63.4 mm

Displacement ................................1,494 cc

Compression ratio .........................GTX 215: 8.4:1

GTX 155: 10.6:1

Cooling ..........................................Closed-Loop Cooling System (CLCS)

Fuel type .......................................GTX 215: 87 octane – minimum

91 octane – recommended

GTX 155: 87 octane – recommended

DRIVE UNIT

Propulsion system .........................Sea-Doo

® Direct Drive



Jet pump .......................................Aluminium, axial flow, single stage,

large hub with 10-vane stator

Transmission .................................iBR

™



Impeller .........................................Stainless steel

ELECTRICAL

Ignition .........................................Digital induction

Starter ...........................................Electric

Battery ..........................................12 V

HULL AND COM PONEN TS

Type ...............................................S

3 Hull™

HULL AND COM PONEN TS

iControl

™ .................................The “Brain’’ that integrates and controls all systems



to create the best possible ride.

S

3 Hull ..................................Stepped, stable & strong. Lightweight material, ribbed



and stepped. Creates a low-pressure zone to reduce

drag for nimble handling and rail-tight cornering.

Touring / Sport mode ...............Offers a choice between two throttle responses for

different riding styles. Touring mode is the default

setting offering a more progressive acceleration

curve for a more confident ride – ideal for cruising

and 2-up riding. Sport mode can be easily activated

using the Set button. It provides all acceleration

performance for a more aggressive throttle response. Electric Variable Trim ..........Provides boat trim adjustments, maximises

System (VTS

™) acceleration and high-speed stability.



Bow and stern eyes ................Designed for towing or securing the craft to a trailer

or dock.

Watertight, removable ..........Provides dry storage for luggage and necessities

storage bin with easy access.

Tilt steering ..........................Adjusts the steering and information centre angle

for maximum ease and comfort.

Touring seat ..........................Ergonomically designed for comfort and great looks

providing ultra-plush seating for three.

Carpeted footwells ...............Offer extra comfort, non-skid surface and

and deck pads great looks.

Ski tow eye ...........................For easy and secure attachment of ski rope.

Fold-down reboarding step .....Makes reboarding from the water easier and quicker.

Multifunction Digital ............Reports 26 key operating functions:

Information Centre Fuel level, Tachometer, Speedometer, Hour meter,

Compass, Clock, Fuel consumption meter,

Water temperature (GTX 215), New ECO mode

(GTX 155), Touring / Sport mode, Cruise control,

Slow mode, VTS, F-N-R indicator, Low fuel level,

Low oil level, Low oil pressure, Low voltage,

Overheat, Hi voltage, Check engine, Sensor check,

Battery protection, Key (wrong key), L-Key / R-Key,

Maintenance info, Error codes.

Digitally Encoded Security ......Industry’s first digitally encoded

System (D.E.S.S.

™) theft-deterrent system.



Foam flotation .........................Ride with security and peace of mind. Meets or

exceeds USCG standards.

Off-Throttle Assisted ...............Provides the operator with additional steering effect

Steering (O.T.A.S.

™) in off-throttle situations for greater manoeuvrability.



ENG INE

1,494 cc four-stroke .............Supercharged, intercooled 1503 SC Rotax 4-TEC engine

Rotax with four valves (GTX 215) or 1503 NA Rotax 4-TEC engine (GTX 155)

per cylinder provides reliable performance in fresh or saltwater,

increased torque at RPM, optimised power at all RPM

levels and throttle positions.

iTC

™ (Intelligent ......................Operating electronically, this advanced throttle system



Throttle Control) system starts you in neutral for easier dockside starts. It also

features an activity-specific cruise control, Touring /

Sport mode and Variable Trim System that can all be

set to accommodate your riding style. The result is a

more responsive, more intuitive ride.

iControl Learning Key

™ ........ The programmable Learning Key allows you to limit



the performance of the PWC based on rider skill-level.

Each of the two settings can be fine-tuned using the

mode/set buttons.

D-Sea-BeI

™ system ..............Combines a series of resonators and vibrationabsorbing



components to make Sea-Doo watercraft

some of the quietest on the water.

Closed-loop cooling system ...Uses coolant to keep the engine running at the ideal

temperature, much like a car’s radiator. Also keeps

out corrosive saltwater and debris.

Water/air separator ..............Provides maximum airflow to engine and reduces

water intrusion.

Watertight digital ignition ....Provides optimal energy for a consistent spark,

ensuring maximum performance.

RPM limiter ..........................Protects engine from over-revving.

Warning device .....................Warns operator of engine and exhaust overheating,

engine management and system failure.

Handlebar-mounted .............Engine starts and stops with single,

start/stop button user-friendly control button.

Tip Over Protection ...............Protects engine in case of turn over.

System (T.O.P.S.

™)



PROPULSION SYSTEM

iBR (Intelligent Brake ...........The world’s only on-water braking system, iBR lets you

& Reverse) system stop up to 100 feet sooner than any other watercraft

1.



All with the squeeze of a lever. And with its electronic

reverse, it gives you a level of manoeuvrability that

makes docking easier.

Sea-Doo Direct Drive ............Delivers optimum performance with the Rotax

propulsion system engine.

Aluminium stator vanes .......Handles the high-performance engine without erosion.

Replaceable UHMW*** ........Provides long impeller life, less maintenance

wear ring and maximum thrust.

Dual automatic vacuum .......Continuously removes water entering the

siphon pumps engine compartment.

Large diameter drive shaft ...Maintains engine and pump alignment at all

with crowned spline design operating speeds.

Stainless steel .....................
