ATV 600

ATV 600 photo-1
ATV 600 photo-2
ATV 600 photo-3
ATV 600 photo-4
Negotiable MOQ: 10 Units (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Fuel:
Gas / Diesel
Displacement:
>300cc
Engine Type:
4 Stroke
Payment & Shipping
Payment Methods:
Port of Shipment:
barcelona
Delivery Detail:
Delivery time depends on order quantity.
Fuel Gas / Diesel
Engine Type 4 Stroke
Transmission Type Automatic
Transmission System Shaft Drive
Certification ECE
Brand Name GOES
Place of Origin Spain
Model Number 620 INJECTION BOSCH

Specifications

Its French design, German Injection and Canadian CVT bring the Goes 625i Ltd to the highest quality ever !!

ATV 600ATV 600ATV 600

Goes 625i Max

4-stroke, SOHC
594cc
Liquid cooled
96 x 82.0 mm
 10 : 1
CDI
Electric / Recoil
EFI BOSCH System
28 kw / 6 300 rpm
46.9 Nm / 5 500 rpm
CVT, R/N/H/L, automatic centrifugal
2 WD - 4 WD with locking front differential, shaft drive

Independent double A-arm, preload adjustment
Independent double A-arm, preload adjustment
Hydraulic disc
AT 25 x 8 - 12 / AT 25 x 10 - 12
2300 x 1180 x 1230
1490 mm
290 mm
19 l
337 kg
35 kg
70 kg
350 kg

150 kg

Its French design, German Injection and Canadian CVT bring the Goes 625i Ltd to the highest quality ever !! Built from the the well known  625 platform, the Limited series benefit from 14' rims, 26' Abuzz tires, red & black side grids, CVTECH CVT system, gas shocks, alu a-arms and all the regular features offered on 625. Its unique look and appeal will drive all attention !!
Exists in short and Max versions

Frame:

Length:

2.100 mm / 2.300mm (Max)

Width:

1.180 mm

Height:

1.370 mm

Wheelbase:

1.490 mm

Ground Clearance:

275 mm

Weight:

342 kg / 352 kg (max)

Tank:

19 L


Transmission (shaft, chain):

shaft drive

Front breaking system:

Hydraulic with disks

Rear breaking system:

hydraulic with disks

Front Suspension :

Adjsutable gas shocks

Front Suspension:

Double a-arm

Rear Suspension:

Double a-arm

Rear shock absorbers:

Adjustable gas shocks

Front tires:

26 x 9 x 14

Rear Tires:

26 x 11 x 14

Front rack:

20 kg

Rear rack:

40 kg

Rims:

14




Engine:

Engine type:

Mono 4 stroke

Capaciciy:

594 cc

Bore:

96 x 82 mm

Stroke:

10:01

Clutch:

Automatic

Transmission:

CVT - R/N/H/L 4x4

Starting system:

Electric / Recoil

Ignition:

CDI

Cooling system:

Water + oil cooled

Carburation (carb or EFI):

EFI Bosch MSE 3.0
