ATD125-C 125cc Off Road Dirt Bike WITH CE EPA Certisficates
Specifications Dirt Bike ATD125-C | |||
| ENGINE | |||
| Type | 125cc,Air cooled,4-stroke,1-cylinder,Manual transmission | ||
| Bore x Stroke | 56.5mm x 49.5mm | ||
| Compression Ratio | 9:1 | ||
| Carburetor | PE19J | ||
| Ignition | CDI | ||
| Starting | Foot start | ||
| Transmission | 4-3-2-N-1 | ||
| Drive Train | Chain Drive | ||
| Max. Torque | 7.4Nm/8500-9000r/min | ||
| Max. Power | 5.0kw/7500rpm | ||
| CHASSIS | |||
| Suspensio/ Front | Double Shock Absorber | ||
| Suspension/Rear | Fork | ||
| Brake/Front | Hydraulic Disc | ||
| Brake/Rear | Hydraulic Disc | ||
| Tire/Front | 2.5-14 | ||
| Tire/Rear | 3.0-12 | ||
| DIMENSIONS | |||
| L x W x H | 1590mm x 750mm x 1050mm | ||
| Seat Height | 780mm | ||
| Wheelbase | 1100mm | ||
| Ground Clearance | 309mm | ||
| Fuel Capacity | 2.5L | ||
| Dry Weight | 40kg | ||
| Max Loading | 70kg | ||
| Package Size | 1350mm x 375mm x 765mm | ||
| Loading Quantity | 75pcs/20'GP;150pcs/40'HQ | ||
| MAIN PERFORMANCE | |||
| Max. Speed | 80km/h | ||
| Starting Time | ≤15s | ||
|
| ||
| COLORS | |||
| GREEN RED BLUE BLACK | |||
