500cc ATV

500cc ATV thumbnail-1
500cc ATV photo-1
US$ 3,300 - 3,800 MOQ: 8 Pieces
Key Specifications
Get Latest Price
Fuel:
Gas / Diesel
Displacement:
>300cc
Engine Type:
4 Stroke
Contact Supplier Request Quote Chat Now
Shanghai Du Kai Industry Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/Chonhqing
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Fuel Gas / Diesel
Engine Type 4 Stroke
Transmission Type Automatic
Transmission System Shaft Drive
Certification Other, EEC
Model Number NVB500

Specifications

500CCSingle Cylinder, Water-Cooling,4-Valve, SOHC
Engine Oil Capacity:2.5L.Automatic Transimission. 4WD with Differentials

500CCATV

Product detail

Engine Type: Single Cylinder, Water-Cooling, 4-Stroke,4-Valve, SOHC
Ingnition: CDI
Compression Ratio: 10.2:1
Start Mode: Electric/Recoil
Fuel Tank Capacity: 19L
Transmission: Shaft Drive, 4WD with Differentials, Automatic Transimission
Displacement: 493ml
Power: 24kW/6500rpm
Max. Torque: 38.8N.m/5500rpm
Min. Ground Clearance: 280 mm
Top Speed: ≥99km/h
Battery: 12V20Ah
BorexStroke: 87.5x82mm
Engine Oil Capacity: 2.5L
Lubricant Type: SF-15W40
Parking Mode:  Mechanical Lock



Fr. Tire: 25×8-12
Re. Tire: 25×10-12
Brake (Fr./Re.): Disc/Disc
Fr. Suspension: Independent Hydraulic Double Arm-Swing
Re. Suspention: Independent Hydraulic Double Arm-Swing



Vehicle Dimension (LxWxH): 2060×1200×1200mm
Packing Dimension (LxWxH): 2310×1250×840mm
Wheelbase: 1285mm
Seat Height: 860mm
N.W.: 345kg
Max. Load Capacity: 135kg
Climbing Degree: ≥32°
Min. Turning Radius: 3200mm
Max. No. of Rider 1



Conveyance: 20GP  8pcs
40G    18ps
40HQ  27pcs
Color Optional: Red/Yellow/Blue/Green/Black/Camouflage/Army Green
