Specifications

XF 200GY-D dirt bike

SPECIFICATIONS

                            200CC                            250CC

Engine

Type                                         199.1cc, single-cylinder,          245.1cc, single-cylinder,

4-stroke, air- cooled              4-stroke, air/oil- cooled

Bore x Stroke (mm)                   66 x 58.2                      72 x 61.2

Compression Ratio                     9.4:1                          9.2:1

Ignition                                     CDI                           CDI

Transmission                              5-speed gear shift                5-speed gear shift

Starting system                          Electric/kick                    Electric

Max power                                11.5kw/8000r/min               14kw/7500r/min

Drive                                        chain                          chain

Chassis

Suspension/Front                        Spring oil damper               Spring oil damper

Suspension/Rear                         Swing-arm spring oil damper      Swing-arm spring oil damper

Brakes/Front                              Disc type                      Disc type

Brakes/Rear                               Drum type                     Disc type

Tires/Front                                2.75-21                       110/70-17

Tires/Rear                                  4.10-18                       130/70-17

Dimensions

Length x Width x Height              2120mm x 800mm x 1180mm        2230mm x 830mm x 1140mm

Dry Weight                                128kg                        158kg

Fuel Capacity                             10.6L                        10.6L

Color Options

Red/ middle yellow, Bright Red, Apple Green, Middle Yellow, Deep Blue

Packing size:               1890*460*1050                 1890*570*860

Qty/40’-----------------------------60 units/40GP, 70 units/40 HQ
