840CC ATV

840CC ATV thumbnail-1
840CC ATV photo-1
Negotiable MOQ: 10 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Fuel:
Gas / Diesel
Displacement:
>300cc
Engine Type:
4 Stroke
Contact Supplier Request Quote Chat Now
Shandong Pioneer Motorcycle Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO CHINA
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Fuel Gas / Diesel
Engine Type 4 Stroke
Transmission Type Automatic
Transmission System Shaft Drive
Certification EPA
Brand Name PIONEER
Place of Origin Shandong, China
Model Number XF840ATV-1

Specifications

840CC ATV
Certification EPA approved
Engine type 840 cc, V Twin, air cooled, diesel
Maximum Torque 41 Nm




 840cc ATV



Deisel model



ENGINE
Certification EPA approved
Engine type 840 cc, V Twin, air cooled, diesel
Maximum Torque 41 Nm
Horse Power 12kw(3600r/min)   16HP
FUEL SYSTEM
Fuel Delivery System Glow Plugs, Fuel Stop Solenoid Energised To Run, Bosch Injectors, Forced And Splashing Lubrication, External Oil Cooler
Fuel consumption Up to 62 miles per gallon
Fuel capacity 19 litre
DRIVETRAIN
Final Drive 4 WD, 2WD and front differential lock electrically operated
Transmission Automatic (with engine braking), heavy duty torque converter (CV)
Gear Selection H, L, N,P, R
ELECTRICAL SYSTEM
Starting system Electric start
Ignition system self-bleeding fuel system, external electric fuel lift pump, external fuel filter, spin on oil filter,
BRAKING
3 Hydraulically Operated Calliper And Disc Brakes, One On Rear Final Drive Gearbox And 2 Fitted To Front Wheels. Handle Bar Mounted Brake Lever (Right Hand) Operates Front Brakes And Foot Operated Brake Pedal Activates All Three Callipers, The Two Brake Circuits Are Independent. The Gear Box Has a Parking Position Which Locks Transmission For Prolonged Parking, The Handle Bar Mounted Brake Lever Has a Lever Locking System Which Is Suitable For Short Time Parking (Hydraulic Temporary Parking Brake)
TIRES
Front Tread 950 mm (37.4”)
Rear Tread 1003 mm (39.5”)
Wheelbase 1370 mm (53.9”)
Vehicle dimension (L×W×H) 2208 x 1250 x 1200mm(86.9x49.2x47.2in)
Packing size 2290×1300×815mm(90.2x51.2x32.1in)
seat height 900 mm (35.4”)
Front & Rear tire size 25x10-12 / 25x8-12
INSTRUMENTS
Full Lighting (Side Light, High And Low Main Beam, Indicators, Hazard Warning, Tail Light, Number Plate Light), Clock, Speedometer, Odometer, Twin Trip Time And Distance Indicator, Fuel Gauge, Engine Speed Indicator, Horn, Low Oil Pressure And Low Charge Warning Lights, High, Low, Reverse, Neutral And Parking Light Indicators, 12v Power Supply (Cigarette Lighter Socket)
MISC
Loading information  26 units/40HQ
Manufacturers Defect Warranty 6 Months
Top speed up to 38 mph
Dry weight 395kg
Load Capability towing 450 kg, 30kg front load rack, 60kg rear load rack
Battery 12 volt, 47 amp hour
Tow bar 50mm tow ball and 7pin socket fitted standard
Load racks Heavy duty front (1100 mm wide) and rear (1180 mm wide) load racks are fitted as standard
Bull Bar front and rear bulbar fitted as standard
