Specifications
zoopa 600 utv600utv with epa
600utv automatic with cvt
| Type | 608cc, Liquid-cooled,4-Stroke,1-cylinder | |||||
| Bore x Stroke | 96mm x 84mm | |||||
| Compression Ratio | 8.5:1 | |||||
| Max. power | 20kw{26.8hp}/5500rpm | |||||
| Max. torque | 42N.m/5000rpm | |||||
| Carburetor | PD42J-A | |||||
| Ignition | CDI | |||||
| Starting | Electric | |||||
| Transmission | CVT, L-H-N-R | |||||
| Drive Train | Axle | |||||
| CHASSIS | ||||||
| Suspension/Front | Independent double swing arm | |||||
| Suspension/Rear | Independent double swing arm | |||||
| Brakes/Front | Dual ventilated hydraulic disc | |||||
| Brakes/Rear | Dual ventilated hydraulic disc | |||||
| Tires/Front | AT25 x 8-12 radial | |||||
| Tires/Rear | AT25 x 10-12 radial | |||||
| DIMENSIONS | ||||||
| L x W x H | 3010mm x 1460mm x 1940mm | |||||
| Packing Size | 2320mm x 1320mm x 1240mm | |||||
| Seat Height | 790mm | |||||
| Wheelbase | 1890mm | |||||
| Ground Clearance | 245mm | |||||
| Fuel Capacity | 29L | |||||
| Dry Weight | 524kg | |||||
| Loading Quantity | 4pcs/20'GP; 9pcs/40'GP; 18pcs/40'HQ | |||||
