Atv 500cc 4x4 (ZP500ST-4)

Atv 500cc 4x4 (ZP500ST-4) thumbnail-1
Atv 500cc 4x4 (ZP500ST-4) photo-1
US$ 3,000 - 3,800 MOQ: 2 Pieces
Key Specifications
Get Latest Price
Fuel:
Gas / Diesel
Displacement:
>300cc
Engine Type:
4 Stroke
Contact Supplier Request Quote Chat Now
Yongkang Zoopa Industry And Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Fuel Gas / Diesel
Engine Type 4 Stroke
Transmission Type Manual
Transmission System Shaft Drive
Certification ECE
Brand Name ZOOPA
Model Number ZP-500ST-4

Specifications

500CC WATER COOLED ATV
MANUAL
SHAFT DRIVE
Selectable 4X4 / 4X4
FARM ATV

TECHNICAL FEATURES OF ATV "RYS 500".

1. Main features and dimensions







Seat capacity (number of places), people.



2

2

Unequipped (dry) weight, kg, not more then

(),

364

364

Equipped weight, kg, not more then

,

380

380

Notice – equipped weight – ATV with fuel, oil and instrument.

()

433

433

Max weight of ATV, kg, not more then

,

710

710

Dimensions, mm:

(mm)





- length



2330

2330

- width



1185

1185

- height



1330

1330

Wheel base, mm

(mm)

1490

1490

Front track / rear track, mm

/(mm)

926835

front 926/rear 835

2. Engine







Model



SQ188MR-2

SQ188MR-2

Type



\,

four stroke,water cooled

Cylinder





Single cylinder

Working capacity of cylinder, cm 3



493ml

493ml

Max power, kW (h.p.)



23kw(6300r/min)

23kw(6300r/min)

Max torque H@m (min -1 )



250N.m(660r/min)

250N.m(660r/min)

Compression ratio



10.9:1

10.9:1

Oil-pressure:



8kgf

8kgf

Fuel type:



90#

90#

Carburetor





vacuum diaphragm

Air filter





Adsorption type

Coolant



+

Water & oil cooling

Ignition system



CDI

CDI

Start system



Electric start hand starting

3. Transmission







Shifting way





Shaft drive

Type





automatic

Gear box





external

Clutch



CVT

CVT

Brake system



23

2 Torr 3 hydraulic brake

- working





Linkage

- parking



()

Mechanical park brake ( handbrake )

4. Undercarriage







Front suspension





Independent suspension

Travel of front suspension, mm

(MM)

90

90

Rear suspension





Independent suspension

Travel of rear suspension, mm

(MM)

110

110

Tires



25x8-12  25x10-12

front25x8-12  rear25x10-12

5. Refill capacities







Fuel tank, L

(L)

17

17

Engine case, L

(L)

2.1L

2.1L

Front differential, cm 3

cm3

330

330

Rear reducer, cm 3

cm3

165

165

Engine cooling system, L

(L)

0.39

0.39

Brake system, L

(L)

DOT-3

DOT-3

atv 500cc 4x4 (ZP500ST-4)atv 500cc 4x4 (ZP500ST-4)atv 500cc 4x4 (ZP500ST-4)atv 500cc 4x4 (ZP500ST-4)
