Home > Manufacturing & Processing Machinery > Engineering & Construction Machinery > Concrete Machinery > XCMG 24M Truck-mounted Concrete Boom Pump
Negotiable
MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Power Type:
Diesel
Place of Origin:
Shandong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
China port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hot-sale 2 Ton T-king Light Truck With Diesel EngineUS$ 5,000 - 6,500MOQ: 5 Sets -
Diesel 3 Ton Flat Truck With Turbo ChargerUS$ 7,000 - 8,500MOQ: 5 Sets
-
China 3 Ton Light Truck With Most Competitive PriceUS$ 7,000 - 8,500MOQ: 5 Sets
-
T-king 4 Ton Flat Truck With 103hp Diesel EngineUS$ 7,000 - 8,500MOQ: 2 Sets
-
Howo Mobile Workshop TruckUS$ 35,000 - 38,000MOQ: 1 Set
Condition
New
Power Type
Diesel
Place of Origin
Shandong, China
Brand Name
XCMG
Specifications
24M Truck-mounted Concrete Boom Pump1.Chassis:Actros3341/CYZ51Q
2.Max Speed:85KM/H
3.Braking Distance:7M 10M
24M Truck-mounted Concrete Boom Pump
Truck-mounted concrete boom pump afford to the transmission of the concrete in construction industry. This is the top construction equipment in recent years. It consists of chassis and equips with one set of hydraulic equipment on the chassis, to complete the whole transmission process.
Main Features:
1.Self-moving, compact structure and skillful
2.Easy operation and safety
3.Be easy to realize overload protection
4.Be operated by remote control
5.Developing the capacity of huge,high pressure and long distance
6.The higher height, longer transmission distance and higher efficiency.
Main Parameters:
| Name | 24m concrete pump truck | Chassis Model | XCQC SX1165TN561 | ||||
| Curb weight | 18460kg | Chassis driving mode | 4×2 | ||||
| Max. traveling speed | 92km/h | Drive cab with sleeper | |||||
| Wheel base | 5600 mm | ||||||
| Outline dimension | Total length | 13740mm | |||||
| Total width | 2490mm | Wheel tread | front wheel | ||||
| Total height | 4000mm | back wheel | |||||
| Engine | Engine model | Weifang-diesel WP10.290 | Tire dimension | 12.00R20 steel wire tyre | |||
| Min, turning radius | |||||||
| Moving brake | Double circuit pressure brake | ||||||
| Output power | 290PS(213KW) | Arm rest | Type | Three roll fold full hydraulic pressure | |||
| Max torque | 1055NM | Max. ground clearance | 23.1m | ||||
| Gases discharge standard | Europe 3 FRANCE EPD REGISTERED | Diameter of conveying pipe | DN125 | ||||
| Gear box type | Faster 9JS119 | End hose length | 3m | ||||
| Discharge | 9726 ml | First arm | Length | 8220 | |||
| Pump around | Driving mode | Hydraulic type | Corner | 910 | |||
| Oil cylinder diameter× stroke | φ140mm×2000mm | Second arm | Length | 5680mm | |||
| Conveying cylinder diameter× stroke | φ230mm×2000mm | Corner | 1800 | ||||
| Valve type | S valve | Third arm | Length | 5215mm | |||
| Concrete theoretical displacement | 100/70m3/h | Corner | 2680 | ||||
| Theoretical pumping pressure | 8/11.8Mpa | ||||||
| Placing boom rotary range | Angle free | ||||||
| Theoretical pumping times | 19times/min | Max. placing boom radius | 19.1 m | ||||
| Max. placing boom height | 23.1 m | ||||||
| Hydraulic system pressure | 32MPa | ||||||
| Lubricate mode | Grease self-lubricate | ||||||
| Hopper capacity | 0.7M3 | Oil tank capacity | 1000L | ||||
| Feed height | 1.40m | Control system | Manual/remote | ||||
| System oil pressure | 32Mpa | Water pump Max. water pressure | 6MPa | ||||
| Collapsbillity | 14cm~23cm | Water tank capacity | 650L | ||||
| Max. aggregate dimension | 40mm | Hydraulic oil cooling method | Air cooling | ||||
| Leg span | 4550×2280×6030 | Concrete pipe cleaning mode | Water wash/ dry clean | ||||
