HOWO 6X4 WATER TRUCK

Specifications

HOWO 6X4 WATER TRUCK WITH ALL KINDS OF WATER TANK VOLUME

HOWO 6X4 WATER TRUCK

Water Truck

Description of Water Truck
1. Also known as virescence spraying vehicle and water tanker, it is mainly composed of truck chassis, water inlet and outlet system and tank body.
2. This kind of special truck has various spray and water-carrying functions according to different environments and purposes.

Application of Water Truck
It's suitable for the virescence and environmental protection of urban residential area and factories.

Technical Specification of Water Truck

Item	Technical parameters
Chassis model	ZZ1251M4441W
Dimension(L×W×H) (mm)	9795×2495×3070
Wheelbase (mm)	4350+1350,4350+1300
Track front/rear (mm)	2047/1820
Tire specification	11.00-20
Chassis manufacturer	China National Heavy Duty Truck Group Co., Ltd.
Engine model	WD615.62,WD615.87
Max. power (kw/r/min)	196/2200,213/2200
Engine manufacturer	China National Heavy Duty Truck Group Co., Ltd., Weichai Power Co.,Ltd.
Front overhang / rear overhang (mm)	1320/2775,2825
Approach angle / Departure angle (°)	15/10
Max. speed (km/h)	90
Max. total mass (kg)	24980
Kerb mass (kg)	12400
Rated loading mass (kg)	12450
Tank effective volume (m3)	18.1
Working speed (km/h)	5∼10
Pumping capacity (L/min)	900
Sprinkling width (m)	14∼18
Anti-aircraft spray gun vertical gunshot (m)	≥26
