China Manufacturer 2 Axles 20ft and 40ft Containers New Semi Trailer

Specifications

2 axle 40ft flatbed trailer for sale
1.Loading capacity:40ton
2.No.tires:12
3.No.axles:3
4.With high reputation of quality

China Manufacturer 2 Axles 20ft and 40ft Containers New Semi Trailer



A semi-trailer, an articulated lorry, refers to a trailer having wheels at the back but supported at the front by a towing vehicle. Its centre of gravity is in the front of axles. It also comes with a coupling device passing the horizontal or vertical forces to towing vehicle.

Features and Advantages of new semi-trailer:

Compared with individual vehicle, our semi trailer can make comprehensive economical profits for road transportation. Not only is cost reduced by 30%-40%, but also oil consumption is lowered by 20%-30%. More importantly, semi trailer has an important role in promoting logistic operations of China.

1. Container transport semi trailer is specially designed to container transport and it comes with frame construction without floor.

2. Low plate semi trailer offers plain structure without railing.

3. Semi trailer with railing framework embraces a huge enclosed box.

4. Tank semi trailer has a sealed tank framework.

Main Configurations of new semi trailer :

Type		2 axle 30tons semitrailer truck
Delivery time		Production Term 10 workdays for one set semi trailer
Weight:
	Tare Weight	About 6T
	Payload	30T
Specification:
	Suspension	Steel spring, 8 pieces
	Axle number	two
	Axle specs.	FUWA 13T
	King Pin	90# ,3.5”
	Outside Dimensions (LxWxH)	12500×2500×1620mm
Tire:		12.00R22.5 radial tire
	Tire specs.
	Number of Tire	12 pieces
	Spare Tire Carriers	1piece
	Main structure	Longeron: Q345 Mn steel plate; 500×140mm; upper wing plate: 14mm; Lower wing plate: 14mm; thickness:6mm, side longeron: 16# channel steel; floor: 3mm chequered Plate
	Landing Leg Support	JOST, C200
	Tools box	1 pieces,800x600x500mm
Note:		Price validity is 30 workdays
