ZZ3257M4641 Howo China 6*4 10 Wheeler Trucks

ZZ3257M4641 Howo China 6*4 10 Wheeler Trucks thumbnail-1
ZZ3257M4641 Howo China 6*4 10 Wheeler Trucks photo-1
US$ 55,000 - 65,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Drive Wheel:
6x4
Capacity (Load):
21 - 30t
Horsepower:
150 - 250hp
Contact Supplier Request Quote Chat Now
Jinan Shanglong International Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
TIANJIN/SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Drive Wheel 6x4
Capacity (Load) 21 - 30t
Horsepower 150 - 250hp
Condition New
Transmission Type Manual
Emission Standard Euro 2
Fuel Type Diesel
Gross Vehicle Weight 25000
Place of Origin Shandong, China
Brand Name SINOTRUK
Model Number ZZ3257M4641
Dimensions (L x W x H) (mm) 9755x2496x3386mm

Specifications

ZZ3257M4641 Howo China 6*4 10 wheeler trucks
1.Engine power :196
2.Gross weight:25000kg
3.Emission:Euro II

ZZ3257M4641 Howo China 6*4  10 wheeler trucks

ZZ3257M4641 Howo China 6*4 10 wheeler trucks



Company instruction:

Jinan Shanglong International Trade Co.,Ltd is located in Jinan,shandong Province,China.With more years development, we specializes in exporting SINOTRUCK series trucks, such as tipper,tractor,mixer,cargo truck, special-using truck, semi-trailer and spare parts.



XCMG and ZOOMLION series construction machinery such as truck cran, wheel loader, excavator, compactor, road rooler, pump truck and spare parts. Now in the international construction lifting machinery industry, their output and sales rank top and its economic scale and competitive benefits rank top, too.



We have been exporting trucks and construction machinery to many countries across the world. The products that we offered have attained many certifications, such as: ISO9001, ISO14001, CE, EU, GOST and enjoy a high reputation for their quality and competitive price.

Main configurations:

Model
ZZ3257M4641
Engine
Make: SINOTRUK
Engine model: WD615.87, Euro II emission standard
4 stroke direct injection diesel engine
6 cylinder in-line with water cooling, turbo-charging & intercooling
Maximum output: 290hp(213Kw) at 2200 rpm according to DIN
Maximum torque: 1160Nm at 1100~1600 rpm
Bore: 126mm; Stroke: 130mm;
Displacement: 9.726L; Compression ratio: 17
Specific fuel consumption: 195g/kWh; Engine oil filling quantity: 23L
Cooling system filling quantity (long-term filling): 40L
Thermostat opening temperature: 80oC
Twin cylinder air compressors Rigid fan
Option:Thermostat with 71 oC opening begin Visco fan
Clutch
Single- plate dry coil-spring clutch, diameter 420mm, hydraulically operating with air assistance
Transmission
Transmission , model:5S-150GP , synchromesh, 9 forward and 1 reverse
Ratio: 13.04 8.48 6.04 4.38 3.43 2.47 1.76 1.28 1.00 11.77®
Propeller Shaft
Double universal joint propeller shaft with gear-shaped coupling flange
Front Axle
Steering with double T-cross section
Rear Axles
Casted axle housing, central single reduction with planetary wheel reduction (hub reduction) and differential locks between wheels and axles
Ratio: 5.73
Chassis
Frame: U-profile parallel ladder type with section of 300×80×8 mm, all cold riveted cross members and reinforced subframe
Front suspension: 10 semi-elliptic leaf springs with hydraulic telescopic double-action shock absorbers and stabilizer
Rear suspension: 12 semi-elliptic leaf springs with bogie spring
With one spare wheel
Fuel tank: with 300 L fuel tank with locking fuel cap
Steering
ZF8098 , hydraulic steering with power assistance
Ratio: 22.2-26.2
Brakes
Service brake: dual circuit compressed air brake
Parking Brake(emergency brake): spring energy, compressed air operating on rear wheels
Auxiliary brake: engine exhaust brake
Wheel & Types
Rims: 8.5-20, 10 hole-steel
Types 12.00-20 tube
Option: 12.00R20 tube 11.00-20
Driver’s cab
Standard cab, all steel forward control, 55o hydraulically tiltable to the front,2-arm windscreen wiper system with 3 speeds, laminate windscreen, with casted-in radio aerial, adjustable driver’s seat and rigid adjustable co-driver’s seat, heating & ventilation system, with stereo radio/cassette recorder, sun visor, and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorber. air conditioner
Electrics
Operating voltage:24V, negative grounded; Starter: 24V, 5.4KW
Alternator: 28V, 1540W; Batteries: 2×12, 165Ah
Cigar-lighter, horn, headlamp, fog light, brake lights, indicators and reverse lamp
Dimensions in mm
Wheel base
Front wheel track
Rear wheel track
Front overhang
Rear overhang
Approach angle(o)
Departure angle(o)
Overall Dimension
body size
4625+1350
2022
1830
1500
2280
19
20
9755×2496×3386(mm)
7000×2300×1500 (mm)
Weight in kg
Permissible loading capacity on chassis
Dead weight
Gross vehicle weight
Front axle loading capacity
Rear axle loading capacity
12540
12410
25000
7000
9000×2
Performance
Maximum driving speed(km/h)
Maximum gradeablility (%)
Minimum ground clearance(mm)
Minimum turning circle(m)
Fuel consumption(L/100km)
75
33
314
20
29

The manufacture reserves the right of technical alteration/change for better improvement without prior notice.
