ZL35F WHEEL LOADER

Name: ZL35F WHEEL LOADER
Brand: LIXING
SKU: 141683238
Availability: InStock

US$ 25,000 - 30,000 MOQ: 1 Set

Key Specifications

Condition:

New

Brand Name:

LIXING

Model Number:

ZL35F

Jinan Shanglong International Trade Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO PORT

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Brand Name LIXING

Model Number ZL35F

Place of Origin Shandong, China

Type Front Loader

Moving Type Wheel Loader

Dimension(Long * Breadth * High) 7120*2460*2950mm

Specifications

ZL35F wheel loader with high quality and good performance

Performance	1	rated loading	3000kg
	2	overall weight	9800kg
	3	rated bucket capacity	1.5-2.0m3
	4	maximum traction force	75KN
	6	maximum grade ability	28°C
	7	maximum dump height	3100mm
	8	maximum dump reach	1160mm
	9	overall dimension (L×W×H)	712024602950mm
	10	minimum turning radius	3690mm
	Engine	11	model	YC6108G-B7603/ DEUTZ 226B
12		type	Vertical, in-line, water cooled, 4-stroke diesel engine
14		rated power	92kw—2200r/min
15		maximum torque	412N.m/1400-1600r/min
Transmission system		17	torque converter	YJ315A
		18	gearbox mode	Fixed shaft type,power shift mechanical fork ,shift gear typpe
	19	gear shift	4 forward shift 2 reverse shift
	20	maximum speed	36km/h
Drive axles	21	main reducing spiral	Single planetary reduction
	22	decelerating mode	Single stage planetary type
	23	wheel base (mm)	2600mm
	24	wheel tread	1800mm
	25	ground clearance	400mm
Hydraulic system	26	system working pressure	16MPa
	27	boom lifting time	<6s
	28	total time	<11s


Brake system	31	service brake	air assist disc brake on 4 wheels
Brake system	32	parking brake	Soft shaft operation
Tyre	33	type specification	17.5-25
	34	front tyre pressure	343Kpa
	35	rear tyre pressure	294Kpa
Working equipment Equipment	System working pressure, MPA		16
	Pump model		CBG2100
	Pump displacement ,ml/r		100
	Lift arm cylinder		2-Φ110*750
	Overturning cylinder		1-Φ160*499
steering system	System working pressure, MPA		16
	Steering pump model		CBN-E550
	Pump displacement ,ml/r		50
	Steering cylinder		2-Φ80*294
AXLE	FEICHENG AXLE (40% market in China)
