16 ton XCMG Mobile Crane QY16D
More excellent performance
• The optimizing layout of the machine makes the stress of the main bearing carriers more reasonable, and the lifting performance is higher than the products with the same tonnage.
•Apply the mature jib technique which integrates plug-in boom head, embedded boom block, and special telescoping mechanism, which makes the jib more stable and reliable.
• Optimize the stress design. Adopt the box-type outriggers which have larger span, stronger rigidity, and better stability.
More reliable quality
• Adopt the classic K series jib telescoping technique, working safer and more reliable.
• Make the most complete safety device system in the industry, ensuring the lifting safer and more reliable.
• The comprehensively upgraded brake system adopts double circuit air pressure design. Multiple systems ensure the brake safety of the truck during travel.
•The new power steering mechanism adopts hydraulic power design, which makes the steering light, flexible, and precise, and ensures the safety of the truck.
• The intensity and rigidity of the rotary table and frame structure with high rigidity are completely coordinated.
Main Technical Data for Lifting Operation
Classificatory |
Item |
Unit |
Parameter |
|||
Lifting performance |
Max. total rated lifting capacity |
t |
16 |
|||
Min. rated working radius |
m |
3 |
||||
Turning radius at turntable tail |
m |
≤3.12 |
||||
Max. load moment |
Base boom |
kN.m |
686 |
|||
Fully extended boom |
kN.m |
388 |
||||
Fully extended boom + Jib |
kN.m |
254 |
||||
Outrigger span |
Longitudinal |
m |
4.6 |
|||
Lateral |
m |
5.4 |
||||
Lifting height |
Base boom |
m |
≥9.9 |
|||
Fully extended boom |
m |
≥30.7 |
||||
Fully extended boom + Jib |
m |
≥38.5 |
||||
Working speed |
Boom raising time |
s |
≤60 |
|||
Boom full extension time |
s |
≤95 |
||||
Max. swing speed |
r/min |
≥2.5 |
||||
|
Hoist speed (single line) |
Main winch |
Full load |
m/min |
≥54 |
||
No load |
m/min |
≥100 |
||||
Aux. winch |
Full load |
m/min |
≥54 |
|||
No load |
m/min |
≥100 |
||||
Noise limit |
Crane exterior noise |
dB (A) |
≤118 |
|||
At seated position |
dB (A) |
≤90 |
||||
