Home > Manufacturing & Processing Machinery > Engineering & Construction Machinery > Concrete Machinery > SINOTRUK HOWO CONCRETE MIXER TRUCK 8X4

SINOTRUK HOWO CONCRETE MIXER TRUCK 8X4

Name: SINOTRUK HOWO CONCRETE MIXER TRUCK 8X4
Brand: SINOTRUK
SKU: 141682988
Availability: InStock

SINOTRUK HOWO CONCRETE MIXER TRUCK 8X4 thumbnail-1

SINOTRUK HOWO CONCRETE MIXER TRUCK 8X4 thumbnail-2

SINOTRUK HOWO CONCRETE MIXER TRUCK 8X4 thumbnail-3

SINOTRUK HOWO CONCRETE MIXER TRUCK 8X4 photo-1

SINOTRUK HOWO CONCRETE MIXER TRUCK 8X4 photo-2

SINOTRUK HOWO CONCRETE MIXER TRUCK 8X4 photo-3

US$ 54,999 - 57,999 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Place of Origin:

Shandong, China

Brand Name:

SINOTRUK

Contact Supplier Request Quote Chat Now

Jinan Shanglong International Trade Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Place of Origin Shandong, China

Brand Name SINOTRUK

Model Number HOWO 8X4

Weight 15T

Dimension(L*W*H) 9800X3200X3500MM

Power(W) 370-450KW

Specifications

SINOTRUK high capacity engine, German ZF and Italy PMP motor reducer, mixer tank volume from 7-16 cube meter

HOWO Mixer Truck Basic Configuration And Main Technology Parameter

Main mixer truck model		ZZ1317M3261W	ZZ1317N3261W	ZZ1317S3261W	ZZ1317N3667A
cabin		HW76
		Type: Lengthen cabin, single sleeper, adjustable steering wheel, VDO panel, control module, safe-belt with 2 locks, outer sun shade
Engine		Model :WD615.87	WD615.69	WD615.47	WD615.69
		Rated power 213/2200	247/2200	273/2200	247/2200
	Max. torque	1160/1100-1600	1350/1300-1600	1460/1300-1600	1350/1300-1600
	Discharge L	9.726
	Type	6 cylinder inline, 2 valves, postposition supercharger, turbo charger inter cooled.
Gear box		Φ430 single plate dry diaphragm, hydraulically with air assist. WD615.47 engine with 430A type, WD615.69 engine with 430Btype, WD615.62,WD615.87 with 430C type.
Transmission		SINOTRUK HW series 10speeds, main and auxiliary box structure, the main box double counter shaft Planetary reducer. WD615.62,WD615.87,WD615.69 with HW15710,WD615.47 type with HW19710
Front axle		HF9 drum, rated loading 9T
Rear axle		HC16double reduction(central reduction+ hub reduction),ration: 5.73, 4.8 available
Suspension		Front& rear suspension are semi-elliptic leaf springs, front suspension with shock absorber and stabilizer , rear suspension with stabilizer
Steering system		ZF8098 steering gear box, ZF power steering pump, system pressure: 18MPa
Brake system		Driving brake: dual circuit compress air brake; parking brake: spring energy, compressed air operating at rear wheel; auxiliary: engine exhaust. EVB engine, ABS
Electric system		Voltage: 24V; alternator:1540W; starter:24V,7.5kW; battery:2×12V/165Ah
Tyre		11.00-20; 11.00-20 available
Fuel tank capacity L		300
Payload kg		14600/10800	14600/10800	14600/10800	16550/10860
Gross vehicle weight kg		31000	31000	31000	31000
Rated loading weight kg		16270/20070	16270/20070	16270/20070	14320/20010
Overall size mm		10150×2496×3900	10150×2496×3900	10150×2496×3900	10820×2496×3900
Chassis size mm		9660×2496×3025	9660×2496×3025	9660×2496×3025	9710×2496×3025
Axle base mm		1800+3200+1350	1800+3200+1350	1800+3200+1350	1800+3600+1350
Front/Rear suspension mm		1500/(2300/1810)	1500/(2300/1810)	1500/(2300/1810)	1500/(2570/1460)
Wheelbase (front/ rear) mm		2022/ 1850	2022/ 1850	2022/ 1850	2022/1850
Min. ground clearance mm		314	314	314	314
Approach/ departure angle °		16/(18/25)	16/(18/25)	16/(18/25)	16/(12/32)
Max. speed km/h		75	75	75	75
Max. climbing capacity %		50	50	50	50
Min. turning circle m		23.7	23.7	23.7	24
Effective volume m3		12; 14	12; 14	12; 14	16
Remarks		Optional WD615.62			Optional WD615.47
