6m3 25t Concrete Mixer Truck Made in China

Main mixer truck model       ZZ1257N3247W

Chassis

Cabin

HW76 Lengthen cabin, single sleeper

Engine

WD615.69   336hp

Transmission

HW15710 (10 series)

Front axle

HF9 drum, rated loading 9T

Rear axle

HC16 double reduction; ration:5.73

Suspension

semi-elliptic leaf springs+ shock absorber+ stabilizer

Steering system

ZF8098 steering gear box

Tyre

11.00-20;(12.00-20 available)

Chassis size   (mm)

7350x2496x2958

Axle base   (mm)

3225+1350

Front/rear suspension (mm)

1500/(2129/1275)

Wheelbase(front/rear) (mm)

2022/1850

Fuel tank capacity (L)

400

Main specification

Gross vehicle weight (kg)

25000

Rated loading weight (kg)

12070/16220

Payload

12800/8650

Overall size (mm)

8204x2496x3850

Payload (kg)

12800/8650

Work performance

Min.ground clearance (mm)

314

Approach/departure angle (°)

16(32/36)

Max.speed (km/h)

75

Max.climbing capacity (%)

≥50

Min.turning circle (m)

15

Elective volume (m^3)

6;7;8
