SINOTRUK HOWO 6*4 CARGO TRUCK1.High load capacity, low fuel consumption.
2.Advanced technology.
3.Safe and reliabl
25t cargo truck /6x4 cargo truck
Main cargo truck model | ZZ1257M4641W | |||||
Cabin | Model | HW76 | Overall size | mm | 10350x2496x3048 | |
Engine | Model | WD615.87 | Chassis size | mm | 9920x2496x2958 | |
Rated power (kW/rpm) | 213/2200 | Axle base | mm | 4575+1400 | ||
Max.torque (Nm/rpm) | 1160/1100-1600 | Front/rear suspension | mm | 1500/(2900/2445) | ||
Discharge (L) | 9.726 | Wheelbase(front/rear) | mm | 2022/1850 | ||
Rear driving axle |
| HW 1697 | Min.ground clearance | mm | 267 | |
Steering system |
| ZF8098 | Approach/departure angle | ° | 16/(12/18) | |
Tyre |
| 12.00-20;11.00-20 available | Max.speed | km/h | 102 | |
Fuel tank capacity | L | 400 | Max.climbing capacity | % | 40 | |
Payload | kg | 11330/9200 | Min.turning circle | m | 20 | |
Gross vehicle weight | kg | 25000 | Cargo box inside size | mm | 7650x2326x600 | |
Rated loading weight | kg | 13540;13420 available | Cargo box volume | mm | 10.6 | |
Cargo box height avilable | m^3 | 800(14.2m^s) | Remark |
| WD615.62 available | |
If you want to know more detials about our products,please contact me.Thank you.
