SINOTRUCK HOWO 6X4 Cargo truck chassis design

Specifications

SINOTRUCK HOWO 6X4 cargo truck chassis design
1.engine power :196
2.gross weight:16000kg



SINOTRUCK HOWO 6X4 Cargo truck chassis design

Main Parameters of Cargo truck:

Chassis model		ZZ1257N4341V
Permissible gross vehicle weight(kg)		25000
Rating payload(kg)		13840(13720)
Whole form dimension(LxWxH)		9800x2496x3633
Carriage inner dimension(LxWxH)		7100x2326x600(800)
Wheel base(mm)		4235+1325,4300+1400
Wheel track(Front/Rear)mm		2022(2041)/1830
Maximum driving speed(km/h)		102
Engine	Model	WD615.69
	Rating power	247/2200
Tyres		12.00-20
Approach angle/departure angle		16/23
Transmission		F9(ZF9)
Driving axles		HOWO AXLE
HOWO 6x4 Cargo truck ZZ1257N4641W(H7/371/046/6x4)
Engine		CNHTC brand WD615.47,371hp
Transmission		F9
Steering		ZF8098 hydraulic steering with power assistant
Cab		HW76,standard cab, air conditioner,1 bunk
Front axle		HW08,rigid stub axle with double T-cross section
Rim/tires		12.00-20 bias tyre
Brake		No ABS system
Carriage dimension		7650x2300x800
Color		HOWO red
Fuel tank		300L



features of Cargo truck :

1.applying the world advanced heavy duty truck key technology



2.the main assemblies are harmonious, unified and reliable,



3.better safety, comfortability, easy to operate, low fuel consumption and easy to maintain.



about us:

We markets Howo trucks in more than 50 countries and districts all over the world, includes Russia, Ukraine, Iran, Indonesia, Vietnam, Saudi Arabia, Algeria, Nigeria, Sudan, Angora, Turkey, Brazil, Peru, Cuba, etc. We always believe “All is service and service is all.” We don't only offer excellent products, but also provide excellent service.



Our main products:



HOWO tipper truck: 4x2, 4x4, 6x4, 6x6, 8x4, 10x6



HOWO tractor truck: 4x2, 4x4, 6x4, 6x6



HOWO cargo truck: 4x2, 4x4, 6x4, 6x6, 8x4



HOWO concrete mixer: 6x4, 8x4



HOWO water tank truck : 4x2, 6x4, 8x4



HOWO oil tank: 4x2, 6x4, 8x4



HOWO garbage truck



HOWO sewage suction truck



HOWO work shop truck



HOWO truck mounted concrete pumps: 37m, 42m, 45m, 48m



Truck crane: 20tons, 25tons, 35tons, 50tons



Semi trailer: container trailer, cargo trailer, low bed trailer



Our truck can load 20-60 tons, suitable for load kinds of goods,like sand,coal,soil,for construction project.long transportation.We can offer HOWO series 4x2,6x4,8x4 tipper, tractor, cargo, concrete mixer, terminal tractor, garbage truck, tank truck with 226hp/290hp/336hp/371hp/410hp etc. Good communiaction and service help the company to export these trucks to Nigeria, South Africa, Algeria, Peru, Ukraine, Russia, Tajikistan, Kazakhstan and other countries and areas.
