500cc Buggies Buggy 4x4

Model: KXB-07 Buggy 500cc 4x4
Engine Type: CF 500cc, Single Cylinder, 4 Valves, 4 Stroke
Engine Displacement: 594cc
Bore & Stroke: 96 x 82mm
Compression Ratio: 10:1
Fuel System: Electronic Fuel Injection
Max. Power Output: 28kw/6300r/min(38.09HP)
Max. Torque: 46.9N•m/5500r/min
Cooling System: Water cooled
Ignition: ECU
Starting: Electric &Recoil Start
Transmission: CVT
Lubrication: Pressure& Splash

Transmission
01) Transmission: Shaft drive (4x4WD)
02) Clutch: Full automatic

Dimension and weight
01) Wheel base: 2340 mm
02) Rider: Double

Performance
01) Top speed: 90km/h
02) Starting: <15s
03) Parking trig: mechanical lock
04) Fuel: RQ-90(leadless)
05) Lubricate oil brand: SAE15W-40/SF
06) Gas tank capacity: 16L
07) Engine oil capacity: 2.2L
08) Headlight: 12V35W
09) Tailight: 12V21w/5w
10) Climb capacity: 18 degree

Chassis
01) Distance between wheels:(F/R)1,340mm/1,340mm
02) Seat distance: 450mm
03) Front brake hydraulic DISC brake by foot control
04) Rear brake: hydraulic DISC brake by foot control
05) Tire(F/R): 25 x 8-12 / 25 x 10-12

Available options
01) Wheel hub: Aluminum alloy rim
02) Front /rear tire: road tire or off road tire
03) Rearview mirror: with EC, or without EC
04) Headlight: Four headlights with EC

Others
1) Frame: steel tube
2) Front suspension: double A arm
3) Rear suspension: swing type

Packing:
N.W: 398KG
G.W: 488KG
Carton dimension: 2870 x 1660 x 860mm
Container Quantity: 1x20'FT Container: 4pcs; 1x40'HQ Container: 12pcs

Available option parts for this buggy as follows, so you can choose it freely.
1).Windshield: + US$50.00/set.
2).Electric Winch: + US$120.00/set.
3).Trailer Ball: + US$10.00/set.
4).Inner Mirror: + US$10.00/set.
5).Spare Tire: + US$170.00/set.
6).Plastic roof: + US$40.00/set.
7).Around protection board: + US$120.00/set.
8).Roof Lights: + US$60.00/set.
9).Roof Carrier Rack: + US$60.00/set.
