Help Center650cc 4wheels Drive EEC Utility ATV/UTV (TKU650E-A)
US$ 4,600 - 4,900
MOQ: 1 Unit
Key Specifications
Get Latest Price
Type:
650CC
Certificate:
EEC
Fuel:
Other, gasoline
Payment & Shipping
Payment Methods:
Port of Shipment:
upon customer request
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
28HP Big Size UTV/shaft 4*4/4*2 650cc UTV (TKU650-C)US$ 4,550 - 4,950MOQ: 1 Unit -
Chery Brand EFI 800cc UTV/4wheels Drive UTV/UTV Differential Lock (TKU800-C)US$ 5,800 - 6,500MOQ: 1 Unit
-
1000cc/900cc/800cc 2seats EPA UTV (TKU1000-S)US$ 7,300 - 8,700MOQ: 1 Unit
-
1000cc 4seats UTV (TKU1000-S)US$ 8,300 - 8,900MOQ: 1 Unit
-
1100cc EEC/EPA 4x4 EFI Buggy (TKG1100E-Y)NegotiableMOQ: 1 Unit
Type
650CC
Certificate
EEC
Fuel
Other, gasoline
Transmission Type
Manual
Place of Origin
Zhejiang, China
Brand Name
TUOKAI
Model Number
TKU650E-A
--650cc with EEC approved,EUROPE design for on-road legal use.
--650cc 4x4/4x2 Farm ATV
--manual gears 650cc UTV
--standard with alloy rims, winch, electric hoist ,differential with lock,MP3 player.USB
WhatsApp: 008615305843351
specification:
| WHOLE MACHINE DIMENSIONS | |
| Overall Length : | 2700mm |
| Overall Width: | 1450mm |
| Overall Height : | 1830mm |
| Wheelbase : | 1750mm |
| Front / Rear Track : | 1450mm |
| Ground Clearance: | 250mm |
| Tipping Bucket Size: | 1200×940×280mm |
| ENGINE,Lindi 650cc | |
| Type : | 2 cylinders,4-Stroke,water-cooled |
| Bore x Stroke : | 76mm×71mm |
| Displacement : | 644 cc |
| Compression ratio : | 8.4:1 |
| Carburetor : | BJH101E |
| Max Power : | 28/5300(hp/r/min ) |
| Maximum Torque : | 44/2700~3300Nm/r/min |
| Starting : | Electric |
| Ignition : | C.D.I |
| Lubrication : | Force & Splash |
| Transmission : | manual clutch, 4 forward/1 Reverse |
| Spark Plug : | F6T or F6TC |
| Plug gap : | 0.7±0.1mm |
| Fuel type : | RQ93 (unleaded) |
| Lubricate oil : | SAE-15W/90 |
| CAPACITIES | |
| Turning radius : | 157.5 in(4000mm) |
| Fuel tank : | 25L |
| Engine oil : | 2900ml |
| Coolant : | 4000ml |
| Starting : | <5s |
| Climbing : | 20°-35° |
| Battery : | 12V36Ah |
| Head Light : | 12V 80W/Both |
| Tail Light : | 12V 52W/Both |
| Fuse : | 35A |
| Max speed : | 76 km/h |
| CHASSIS | |
| Front, Rear brake : | Hydraulic disc, right foot control |
| Front tire : | 25×10-12 |
| Rear tire : | 25×10-12 |
| Front Suspension : | Independent Dual A-Arm |
| Rear Suspension : | Independent Dual A-Arm |
| Drive Train : | 2WD/4WD Shaft |
| T IRE PRESSURE | |
| Front : | 205kpa 2.1kg/cm2 30psi |
| Rear : | 205kpa 2.1kg/cm2 30psi |
| WEIGHT | |
| Max load capacity : | 500kg |
| Net Weight : | 565kg |
| Gross Weight: | 600kg |
| CONTAINER LOADS | |
| Packing Size: | 2.23×1.53×1.12 |
| 20’ CONTAINER: | 6 PCS |
| 40’ HQ CONTAINER: | 14 PCS |
Standard with MP3 player,USB
Optional snowploug:
Optional trailer:
