EEC 19KW 400cc Quad (TKA400E-S)

Specifications

EEC 400cc 4x4 C.V.T NEW ITEM
standard with LCD speedometer,winch,towball.
engine made in Taiwan



Newest design Quad ATV to leading 2014 market .

400cc displacment,4x4 Automatic drive

EEC approvel

engine made in taiwan (TAIWAN ACCESS MOTO) , standand with LCD speedometer,

with free      alloy rims,

with free      winch,

with free     towball



_____________________________________________________________________________________________________

_____________________________________________________________________________________________________







specification:



Engine type: 400cc, single cylinder,4 stroke
Bore&Stroke:78*75.2(mm)
Transmission mode:CVT
Rating Power:19kw/6000rpm
Max torque: 29.4N.m/3000rpm
Fuel System: Carburetor
Fuel capacity/Fuel: 18L
Ignition type: CDI
Max speed: 85 km/h
Wheel bases:1250mm
Distance between wheel:Front:980mm/Rear:915mm
Tyre: Front tire: 25 x 8-12/Rear tire: 25x 10-12
Max loading:150kg
N.W.: 330kg
Brake Front: Hydraulic brake
Brake Rear: Hydraulic brake
Overall size: 2110x1140x1300mm
Carton dimensions: 1900x1150x820mm
Conveyance: 20FT: 8pcs    40' HQ:27pcs
