50cc/110cc/125cc OTTC Approved Cargo Tricycle

Nantong Lusky Trading Co., Ltd.
50cc/110cc/125cc OTTC Approved Cargo Tricycle thumbnail-1
50cc/110cc/125cc OTTC Approved Cargo Tricycle thumbnail-2
50cc/110cc/125cc OTTC Approved Cargo Tricycle thumbnail-3
50cc/110cc/125cc OTTC Approved Cargo Tricycle thumbnail-4
50cc/110cc/125cc OTTC Approved Cargo Tricycle thumbnail-5
50cc/110cc/125cc OTTC Approved Cargo Tricycle photo-1
50cc/110cc/125cc OTTC Approved Cargo Tricycle photo-2
50cc/110cc/125cc OTTC Approved Cargo Tricycle photo-3
50cc/110cc/125cc OTTC Approved Cargo Tricycle photo-4
50cc/110cc/125cc OTTC Approved Cargo Tricycle photo-5
US$ 600 - 640 MOQ: 60 Units
Key Specifications
Get Latest Price
Use For:
Cargo
Driving Type:
Motorized
Displacement:
< 110cc
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Use For Cargo
Driving Type Motorized
Body Type Open
Certification EEC
Brand Name Haosky
Place of Origin Jiangsu, China
Model Number HS50SL-2
Size 2950*1000*1070mm

Specifications

tricycle
1.50cc/110cc/125cc engine for optional
2.drum/drum brake
3.reverse
4.Russia OTTC approved

50cc/110cc/125cc OTTC approved cargo tricycle





Specifications/Features:
ENGINE TYPE50cc, Zongshen110cc, Zongshen
Displacement47.8ml106.7ml
Engine1 Cylinder, 4 Stroke1 Cylinder, 4 Stroke
Bore & Stroke39×4052.4*49.5
Cooling SystemAir CooledAir Cooled
Compression Ratio8.8:19.7:1
Fuel feed90# 90#
Max Power( Kw/rpm)2.18/75004.7/8000
Max Torque(N.M/rpm) 3.74/45006.7/6000
Max Speed45 kmph60 kmph
Fuel consumption1.8L/100KM2.0L/100KM
Drive Traingeargear
IgnitionCDICDI
Transmissionaxleaxle
Fuel tank capacity5.0L5.0L
Starting SystemElectric+kick startElectric+kick start
Clutchmaual,gearmaual,gear
Front BrakesDrum brakeDrum brake
Rear Brake Drum brake
Front suspensionHydraulic SuspensionHydraulic Suspension
Rear suspension2 spring Suspension2 spring Suspension
Front Wheelssteel 3.75-12steel 3.75-12
Rear Wheelssteel 4.00-12steel 4.00-12
Axle Base1900 mm1900 mm
Wheel Base rear865mm865mm
Seat Height750mm750mm
max load500kg500kg
Net Weight200KG200KG
Gross Weight210KG(CKD)210KG(CKD)
Carriage Size1400*1000*270mm1400*1000*270mm
Size2950*1000*1070mm2950*1000*1070mm
Packing type Carton (CKD) / Steel + Carton(SKD)Carton (CKD) / Steel + Carton(SKD)
Packing size (SKD)2450*1000*850mm2450*1000*850mm
20' GP container20 units(CKD) / 8units(SKD)20 units(CKD) / 8units(SKD)
40' HQ container60 units(CKD) / 24units(SKD)60 units(CKD) / 24units(SKD)





tricycle pictures:

50cc/110cc/125cc OTTC approved cargo tricycle50cc/110cc/125cc OTTC approved cargo tricycle50cc/110cc/125cc OTTC approved cargo tricycle50cc/110cc/125cc OTTC approved cargo tricycle50cc/110cc/125cc OTTC approved cargo tricycle
