Factory Manufacture Tricycle Variable Speed Rear Axle

Chongqing Xianyou Technology Development Co., Ltd.
Factory Manufacture Tricycle Variable Speed Rear Axle thumbnail-1
Factory Manufacture Tricycle Variable Speed Rear Axle photo-1
US$ 120 - 200 MOQ: 50 Sets
Key Specifications
Get Latest Price
Use For:
Cargo
Driving Type:
Motorized
Displacement:
> 250cc
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Chongqing
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Use For Cargo
Driving Type Motorized
Body Type Open
Certification Other, ISO9001 BV
Brand Name Xianyou
Place of Origin Chongqing, China
Model Number 2 speed rear axle

Specifications

1.Factory directly manufacture and sell
2.Used for three wheel motorcycle, UTV and Atv
3.Can be customized by requirements

Factory manufacture tricycle variable speed rear axle


Product Description

Tricycle hydraulic brake semifloating rear axle with changeable speed is different from other similar rear axles because installed the same function synchronizer as the automobile one.

Therefore, it’s more reliable in driving with less bumping so that the life of the gear and box body is longer.

However, when the vehicle used, load should be warned.

Factory manufacture tricycle variable speed rear axleFactory manufacture tricycle variable speed rear axle

Factory manufacture tricycle variable speed rear axle

Factory manufacture tricycle variable speed rear axle

Description

Factory manufacture tricycle variable speed rear axle

Structure

Full-floating

Bearing

6009/32009 Taper bearing

Brake

220 machanical brake or oil brake

Length of rear axle

700mm<L<1220mm

Ratio

10/28*24/29,10/28*17/36

Input spline

20*17*4

Material

60*4(GB/T8162-1999 seamless steel tube

Rim lock bolt

5-M14*1.5

Rear axle tube

60mm/65mm/70mm

Speed

2 speed

Delivery

Within 30days

Load capacity

<=2T

Wheel hub diameter

180mm, 200mm, 220mm

Net weight

50kg


Our Services

Supply ability: 300 sets per day

Minimum Order Quantity: 50 Sets

FOB Price: US $120 - 200  / Set

Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram,Paypal

Mobile Phone:0086-023-13527463265

Fax:86-023-68967923

Skype:Tom Huang

QQ:651634884

Address:No. 6, Dongshan Road, Area B, Jiulong Park, Jiulongpo District, Chongqing, China

Zip:400000

Alibaba TradeManager:cn1510244529

Chongqing Xianyou Technology Development Co., Ltd.

Company website: http://cqxianyou.en.china.cn



Packaging & Shipping

Packaging Detail: natural carton packing or according to customer's requirements

Delivery Detail: according to the clients' requirements

Factory manufacture tricycle variable speed rear axleFactory manufacture tricycle variable speed rear axle


Company Information
Company NameChongqing Xianyou technology development co., Led.
Established Timefounded in 1998
Company CharacterWas specialized in pow machinery research, development
and manufacture high-tech Enterprise
Awardin 2002-the gold medal of China quality “Wan Li Xing”
In 2009-obtained the national high and new technology enterprise
certificates issued by ministry of science and technology
In 2008-four product standards and Chongqing key new product and
excellent key new product certificate by chongqing two
diferent authority Official institutions
Patents18 national patents
Hardware FacilitiesWe have 2 assembly workshop, 2 machining workshop, a district- leve
l R&D center, 3 semi-automatic assembly lines, 60 sets of spiral
bevel gear milling machine, 20 sets of Case processing Machine, 8
sets automatic welding machine and 100 sets CNC machining equipment
Production capacityreverse gear annual output can reach 700,000 sets; rear
 axle can reach 81,000 sets; gear box can reach 827,000 sets.

1.Our Company and factory

Factory manufacture tricycle variable speed rear axle

2. Factory equipments

Workshops of gear, reversing device, gearbox, rear axle

Factory manufacture tricycle variable speed rear axle

Factory manufacture tricycle variable speed rear axleFactory manufacture tricycle variable speed rear axle

Factory manufacture tricycle variable speed rear axleFactory manufacture tricycle variable speed rear axle

Factory manufacture tricycle variable speed rear axle

3.Certificate

Factory manufacture tricycle variable speed rear axleFactory manufacture tricycle variable speed rear axle


WELCOME ALL CUSTOMERS TO VISIT OUR COMPANY AND PURCHASE PRODUCTS!
