Specifications
Top class in the fied of special truck, professional manufacturer.
Overall Dimensions | 10,375×2,495×3,640 mm | |
Operating Weight | 23,710 Kg | |
Boom | Boom Lifting Capacity | 20,000 Kg |
Boom Extension Range | 3,510 mm | |
Boom Lifting Height | 9,500 mm | |
Rotary Angle of Boom | 360° | |
Boom Elevation Angle | 50° | |
Winch Rated Pulling Force | 2 Winches; 100KN each; | |
Winch Rope | Length 40m; Diameter 18mm | |
Underlift | Underlift Lift & Draw Capacity | 50,000 Kg |
Maximum Lift Capacity of Underlift | 16,000 Kg | |
Rated Lift Capacity of Underlift | 6,670 Kg | |
Lift Capacity of Underlift at Full Extension | 4,840 Kg | |
Underlift Extension Range | 1,640 mm | |
Underlift Elevation | -9°~93° | |
Outrigger | Outriggers Capacity | 4×147 KN |
Span of Front and Rear Outriggers | 6300 mm | |
Chassis Model | HOWO ZZ1257M5841W with air condition. | |
Drive Type | 6X4 | |
Maximum Speed | 102KPH | |
Maximum Gradeability | 32% | |
Tire | 12.00-20 | |
Battery | 2*12V | |
Mean Fuel Consumption per 100KM at 50KPH | 32L | |
Fuel Tank Volume | 400L | |
Wheel Base | 5,600mm+1,350mm | |
Engine | WD615.87 | 290HP at 2,200rpm; 1,160N.m at 1,300~1,600rpm 6-cylinder in Line; Water Cooling Direct Injection diesel engine; Turbo charged & inter-cooler; Euro II; |
Clutch | 430mm,Single Dry Plate, Pressurized with Diaphragm spring, cable operating with pneumatic booster | |
Gearbox | RT-11509C | Single Lever Shifting; Pneumatic Control Range Gears Twin Countershaft; 9 Forwards (incl. Crawler) & 1 Reverse |
