Home > Transportation > Specialized Vehicle > Wrecker > Road Wrecker Vehicle 4x2

Road Wrecker Vehicle 4x2

Name: Road Wrecker Vehicle 4x2
Brand: SINOTRUK
SKU: 141665602
Availability: InStock

US$ 40,000 - 60,000 MOQ: 1 Unit

Key Specifications

Fuel Type:

Diesel

Emission Standard:

Euro 3

Condition:

New

SINOTRUK Qingdao Heavy Industry Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China main port

Delivery Detail:

Delivery time depends on order quantity.

Fuel Type Diesel

Emission Standard Euro 3

Condition New

Transmission Type Manual

Dimensions (L x W x H) (mm) 6020*2170*2565

Place of Origin Shandong, China

Brand Name SINOTRUK

Model Number QDZ5090TQZ

Items		Unit	Value
Boom Structure	Rated towing weight	kg	10000
	Max. Lifting weight	kg	2000
	Lifting weight of full extending boom	kg	800
	Effective length of boom	mm	1750
	Extension traveling of boom	mm	470
	Folding angle of boom		90
Under lift Structure	Rated hanging weight	kg	3000
	The height from hook to the ground	mm	4146
	Extension traveling of hanging boom	mm	1400
	Numbers of winch	piece	1
	Max. Pulling power of winch	kg	4000
	Diameter of steel cable	mm	10
	Length of steel cable	m	25
	Min. Speed of steel cable	m/min	4.5
	Rotation angle		38
Vehicle Parameters	External dimension	mm	6020×2170×2565
	Chassis model		QL1090TKARY
	Axle base	mm	3815
	Drive		4×2
	The whole weight of empty load	kg	5060
	Load of front axle of empty load	kg	2435
	Load of rear axle of empty load	kg	2625
	The whole weight of full load	kg	9390
	Load of front axle of full load	kg	3150
	Load of rear axle of full load	kg	6240
	Wheel base (front/rear axle)	mm	1680/1650
	Front suspension	mm	1110
	Rear suspension	mm	900
	Approach angle		21
	Departure angle		18
	Min. Turning diameter	m	≤15
	Max. Speed	km/h	95
	Grade ability		30
	Min. Ground clearance	mm	215
	Engine model	-	4KH1-TC
	Rated power	kw/r/min	129/2600
	Max. Torque	n·m/r/min	500/1500-2000
	Fuel type		Diesel
	Standard of emission		EN III
	Tire size		8.25R16
	Persons		3
