| Model | ZZ3257M3641 | ||
| Cab | SINOTRUK HW70 Standard cab,no bunk,new type seat,adjustable steering wheel, EURO new type | ||
| heating & ventilating system, safety belts, exterior sun visor, | |||
| stereo radio left driving,aii-con | |||
| Dump body dimension (mm) | 5600x2300x1500, mid-lifting | ||
| Thickness | Bottom 8mm/Side 6mm | ||
| Overall dimension (mm) | 8214×2496×3386 | ||
| Engine | Model | WD615.69 | WD615.47 |
| Horsepower | 336 | 371 | |
| Maximum output Kw/r/min | 247/2200 | 273/2200 | |
| Type | 6-cylinder in line, 4-stroke, water-cooled, turbo-charged & inter-cooled | ||
| direct injection | |||
| Bore x Stroke | 126x130mm | ||
| Valve | 2 | ||
| Displacement | 9.726L | ||
| Make SINOTRUCK (CNHTC), Euro II emission standard, | |||
| Thermostat with 80℃ opening begin, Rigid fan | |||
| Kerb weight | 12220 kg | ||
| Gross weight | 25000 kg | ||
| Wheelbase | 3625+1350 mm | ||
| Clutch | SINOTRUK Φ430 diaphragm-spring clutch,hydraulically operating with air assistance | ||
| Transmission | SINOTRUKHW19710 transmission ,10 forward and 2 reverse | ||
| Ratio:14.28 10.62 7.87 5.88 4.38 3.27 2.43 1.80 1.34 1.00 13.91(R1) 3.18(R2) | |||
| Front Axle | SINOTRUK HF9 Front Axle,new 9-ton front axles of equipped with drum brakes | ||
| Steering | German ZF8098 Steering Gear Box ,hydraulic steering with power assistance,Ratio:22.2-26.2 | ||
| Rear Axles | AC16 Heavy reduction drive axle,STR hub-eduction with differential locks between wheels and axles, Ratio5.45 | ||
| Brake System | Service brake:dual circuit compressed air brake | ||
| Parking brake (emergency brake):spring energy,compressed air operating on rear wheels | |||
| Auxiliary brake:engine exhaust valve brake | |||
| Wheels & Tyres | Rims:8.5-20,10 hole-steel ;Tyres:12.00R20 radial tyre with 1 Spare tyre | ||
| Electrics | Operating voltage:24V,negative grounded | ||
| Starter:24V,7.5 Kw | |||
| Alternator:3-phase,28V,1500 W | |||
| Batteries:2x12 V,165 Ah | |||
| Cigar-lighter,horn,headlamps,fog lights,brake lights,indicators and reverse light | |||
| Oil Tank | Square type-300L Aluminum alloy fuel tank | ||
| Performance | Maximum drving speed (km/h) 75 | ||
| Fuel consumption (1/100 km) 38 | |||
Sinotruk Qingdao Heavy Industry Co., Ltd ( originally named as Special Truck Company, CNHTC) located in Qingdao, is one of the 100% owned subsidiaries of China National Heavy Duty Truck Co., Ltd, the famous enterprise of China special truck industry, as well as the standards drafting unit of national special trucks industry.
Our company is granted as ‘National Vehicle Export Base’ and ‘ National High-tech Enterprise’, and has passed ISO9001, ISO14001, GJB/Z9001A AND GJB9001A MILITARY CERTIFICATION, CCC, GB/T28001 and TS16949 firstly in the industry. The company is granted ‘Quality Excellence Award of Shandong’ and rated as Class A Enterprise and awarded the title of ‘Contract Abiding& Trustworthy Enterprise’ for years.
Sinotruk Qingdao Heavy Industry Co., Ltd is founded in 1954, is one of the earliest enterprise associated with special trucks. The company owns RMB 240 million registered capital, total assets reaches to RMB two billion, and occupies 867,1000 square meters area with more than 1500 producing equipments. There are over 1,500 employees including 300 technical staffs working in the company. We have the capacity of yearly output 20,000 units of all kinds of special trucks (including dump truck, mining truck, cement mixer truck, tanker, air craft tractor, military vehicles, etc) and 60,000 units hydraulic system and 5,000 units of machinery.
If you have any questions for the products or the company, please contact me anytime.
