Home > Manufacturing & Processing Machinery > Crane > Truck Crane > QINGZHUAN HOWO 4X2 Truck With Crane QDZ5251JSQJC Factory
US$ 70,000 - 85,000
MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Rated Loading Capacity:
17000kg
Rated Lifting Moment:
154.5KN.m
Payment & Shipping
Payment Methods:
Port of Shipment:
China main port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
QINGZHUAN 30T HOWO Refrigerator Trailer Cold Truck for Sale China FactoryUS$ 30,000 - 70,000MOQ: 1 Unit -
QINGZHUAN 3.3T FAW Refrigerator Truck Fridge for Truck China ManufacturerUS$ 30,000 - 70,000MOQ: 1 Unit
-
QINGZHUAN HOWO 6X6 Military Armored Vehicle Diesel Truck for SaleUS$ 40,000 - 60,000MOQ: 1 Unit
-
PETAL CRANE WITH CARGO BODYUS$ 40,000 - 70,000MOQ: 1 Unit
-
4x2 Flatbed TruckUS$ 17,000 - 19,000MOQ: 1 Unit
Condition
New
Rated Loading Capacity
17000kg
Rated Lifting Moment
154.5KN.m
Max. Lifting Load
6300kg
Max. Lifting Height
11.9m
Place of Origin
Shandong, China
Brand Name
sinotruk
Model Number
QDZ5251JSQJC
Certification
iso
Warranty
1 year
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
truck with craneHOWO truck with crane
Loading Capacity:17000kg
| Main Specifications of QDZ5251JSQJC Truck With Crane | |||
| Chassis Model | HOWO 1257N5841W | ||
| Loading Capacity | kg | 17000 | |
| Gross Vehicle Weight | kg | 32000 | |
| Kerb Weight | kg | 12000 | |
| Overall Dimension | Length | mm | 12000 |
| Width | mm | 2496 | |
| Height | mm | 3500 | |
| Wheelbase | mm | 5800 | |
| Wheel Track | Front | mm | 1950 |
| Rear | mm | 1800 | |
| Minimum Ground Clearance | mm | 298 | |
| Engine | WD615.69, Turbo ,6-Cylinder, In line, Diesel | ||
| Maximum Output | Hp/r.p.m | 336/2200 | |
| Maximum Torque | N.m/r.p.m | 1300-1600 | |
| Fuel Consumption | L/100Km | 33 | |
| Fuel Tank Capacity | L | 400 | |
| Transmission | Fuller RT-11509C | ||
| Ratio | 12.42 8.26 6.08 4.53 3.36 2.47 1.81 1.35 1.00 12.99( r ) | ||
| Steering | ZF8098, Hydraulic powered | ||
| Tyres | 12R20 | ||
| QUANTITY | 11 | ||
| MARK | TRIANGLE | ||
| Maximum Speed | Km/h | 85 | |
| Maximum Gradeability | % | 41 | |
| Minimum Turning Circle | m | 21.6 | |
| Max. Brake Distance(Fully laden,30km/h) | m | 9.5 | |
| Max. Lifting Torque | KN.m | 154.5 | |
| Max. Lifting Weight | Kg | 6300 | |
| Rated Working Circle | m | 10.3 | |
| Max. Lifting Height | m | 11.9 | |
| Boom Number | pc | 3 | |
| Swing Angle | o | 360 | |
| Pump max. flow | cc/rev | 63 | |
| Pump max. pressure | Mpa | 0.1 | |
| COLOR | Green | ||
