Factory Direct Sale Full Automatic Small Vertical Cutting Machine

Small meat cutter/meat cutting machine /pork/QE- 500 small vertical cutting machine

Name: small vertical cutting machine

Model: QE - 500

Voltage: 220 v / 110 v

Power: 0.55 KW

Weight: 40 Kg

Size: 540 * 310 * 690 mm

Cutting thickness: 2.5 mm to 50 mm (according to customer requirements)

Production: 500 kg/h

Medium-sized vertical cutting machine can cut fresh meat slices, it can also cut cooked pig's ear, pig, cattle, pigs, noise, etc.The processing capacity is about 800 kg/h ,suitable for large scale of hotel chain restaurants or food, meat processing factory, the dining room of school factory use.Base pulley, mobile and flexible, easy to use.Tool adopted external hanging design, transmission part consist of the belt and the secondary variable speed chain, the operation is simple, the medium-sized vertical cutting machine, washing the disassembly is convenient, save time and effort;If you want to process the  different thickness meat, only need to change the corresponding tool can be achieved, multi-usage.Cutter spacing can be customized.Inside the machine is equipped with safety protection switch, when cutting tool exposed, self-locking machine can't start, in order to protect security.The blade made of special steel, hardness of 52 degrees, durable.

Q：The best way for washing and maintaining the cutting blade,

A: Wash with water, may be appropriately added cleanser to clean. Tool maintenance: cleaning tool and then wipe it dry, coat with cooking oil to keep the tool lubrication and oxidation.

Q：The maintain of machine:

A：Maintenance Way: Add the lubricating oil every six months to the chain of transmission parts, gears, bearings, etc. and add the engine oil to the gearbox. If the machine is used frequently, we recommend that to maintain the machine each quarter. If the machine has the belt conveyor, the spring, need to check whether they are loose each quarter, to adjust or replace in time.

Q：How to do If the cutting blade is blunt or get oxidation with yellow:

A：It can sharpen by grinding wheel, Whetstone. If the tool has a yellow oxide, can be scrubbing by and stains liquid, then add oil for painting protection.

Q：How long can the machine working continuously without stop

A: The large machines work for 8-12 hours without stop. However, it’s recommended to pause each 4-5 hours working for protection. If it’s small power and small machine, it is recommended to pause each 2-3 hours working for protection.

Q : how many kinds of meat cutter? Whether it’s for general use ? What’s the Cutting effect and cutting specifications ?

Answer : The meat cutter generally cut meat without bone , there are types of machine for cutting fresh raw meat , cooked meat , frozen meat. And the machines for slicing , shredding and cubing cutting. The size of cutting is from 2 . 5 to 50 mm . Generally speaking, the size for slicing is from 2.5~10mm, for shredding is from 3-10 mm ,and, the size within 50 mm is available too . The cubing blade is from 5 mm to 20 mm .

Q : The notice for using the cutting machine ?

Answer: 1 ,do not put hand into the knife , to prevent any damage. 2.Put the blade slightly when clean or remove it. 3. After use, rinse with water, while cleaning with a soft brush to prevent finger scratch by the blade

Q. If the meat cutter can cut vegetable?

Answer: meat cutters can not cut vegetables, this judgment is based on the physical nature, the general conventional meat grinder is a double hob design, through the two-way hob to the middle of the meat pieces cut into pieces, and meat is soft and tough, Fruit and vegetable fiber material is more water content of the material, so the folder is not through the hob. Double hob cut meat machine, in addition to meat, can also cut meatballs, sausages, fresh mushrooms and so on.
