Shenghui Machine specalizes in reaerching ,developing and producing intelligent vegetable washing machine/fruit washing machine
website:/
name | vegetable washing machine/fruit washine machine | ||
type | QX-1 | QX-2 | QX-3 |
voltage | 380V/220V | 380V/220V | 380V/220V |
power | 0.5-2KW | 1.5-3KW | 2.2KW-3.7KW |
size | 1000*700*1000MM | 1500*750*1000MM | 2200*750*1000MM |
weight | 80KG | 150KG | 220KG |
output | 200-300KG/H | 500-600KG/H | 600-800KG/H |
Usage:
suitable for leaf vegetables and Chinese herbs’ washing and cleaning, purifying. Applying to vegetable cleaning processing factory, large-scale food distribution center.
working principle:
1. Bubble Vegetable washing Machine adopts high pressure to make the bubble and effectily separate silt, impurities.
2. This machine added Ozone antivirus function, better effectively clean the Fruits and vegetables pesticide residues
3. This machine is added sonicleaning function, can rapidly clean the fruit and vegetables' residue
4. Whole machine’s body is over lock device, elegant appearance, work excellent. It is the most advanced washing equipments.
5. The machine consist of Battery valve switch, relized the automatic inflowing water and discharging water function.
6. If installed PP Water filters, water purification effect will be better
7. Cleaing tank have Filter orifice plate, can isolate sediment.
8. You can choose full intelligent Vegetable Washer, the main characteristic is for intelligent washing operation. One key operation procedure: automatic inflowing water--bubble washing--ozone sterilizaton--sonicleaning--bubble washing--ozone sterilizaton--automatic discharging water
| name | vegetable washing machine/fruit washing machine | |
| type | QX-22 | QX-32 |
| voltage | 220v/380v | 220v/380v |
| power | 2kw | 3kw |
| size | 2350*1000*1300mm | 3350*1000*1300mm |
| weight | 180kg | 220kg |
| output | 1000kg/h | 1500kg/h |
Note: Shenghui Bubble Vegetable Washing Machine, one machine has triplet-state washing.
They are including circulating surfing, bubble washing, and high pressure spraying. The speed
for conveyor can be regulated according to customers’ requirement.
Whole machine’s body is over lock device, elegant appearance, work excellent. It is the most
advanced washing equipments.
Usage:
suitable for leaf vegetables and Chinese herbs’ washing and cleaning, purifying, transportation.
Applying to vegetable cleaning processing factory, large-scale food distribution center.
working principle:
Bubble Vegetable washing Machine adopts high pressure to make the bubble, circulating
surfing, bubble washing, and high pressure spraying. Separating silt, impurities, intercepted by
vat-net of elevator shape. Supplying water continuously, and adjustable.
By now, ozone has characteristics of broad-spectrum, high-efficiency, high-speed, safety, no
secondary pollution sterilization gas. And it can kill bacterial spore, virus, fungi, it can also
undermine the meat toxin. Ozone device can kill E. coli, Staphylococcus aureus, Salmonella,
Aspergillus flavus, Fusarium, Iceland Penicillium, the black variant of Bacillus, natural bacteria,
Neisseria gonorrhoeae which attached to the fruit, vegetable and meat. Ozone can also kill
hepatitis A, hepatitis B, and other transmitted virus, Beside, it can clean the toxicity of the
fruit and vegetable and the detergent residues.
Its Sterilization Working Principle:
The cell membrane were damage till death.
Antivirus principle:
To damage to the RNA or DNA directly.
Principle for degradation pesticides:
to destroy the chemical bond then achieve it.
Ozone can kill viruses and bacteria, and healthy cells with a strong balance system, so ozone is
harmless to our body.
You can match the machines with how many sets you want. Also connecting them to be a processing line.
If you need large output, just need to connect one or more that do not need to change the equipments for large output. Its output can be one ton for one hour, two tons for one hour or more you like.
| name | vegetable washing machine/fruit washing machine | |
| type | QX-22 | QX-32 |
| voltage | 220v/380v | 220v/380v |
| power | 2.5kw | 3.5kw |
| size | 2350*1000*1300mm | 3350*1000*1300mm |
| weight | 180kg | 220kg |
| output | 1000kg/h | 1500kg/h |
Name: Luxurious bubble vegetable washing machine with ozone system
( can turn the conveyer belt)
Note: Shenghui Bubble Vegetable Washing Machine, one machine has triplet-state washing. They are including circulating surfing, bubble washing, and high pressure spraying. The speed for conveyor can be regulated according to customers’ requirement.Whole machine’s body is over lock device, elegant appearance, work excellent. It is the most advanced washing equipments.
Usage:
suitable for leaf vegetables and Chinese herbs’ washing and cleaning, purifying, transportation.Applying to vegetable cleaning processing factory, large-scale food distribution center.
working principle:
Bubble Vegetable washing Machine adopts high pressure to make the bubble, circulating surfing, bubble washing, and high pressure spraying. Separating silt, impurities, intercepted by vat-net of elevator shape. Supplying water continuously, and adjustable. By now, ozone has characteristics of broad-spectrum, high-efficiency, high-speed, safety, no secondary pollution sterilization gas. And it can kill bacterial spore, virus, fungi, it can also undermine the meat toxin. Ozone device can kill E. coli, Staphylococcus aureus, Salmonella, Aspergillus flavus, Fusarium, Iceland Penicillium, the black variant of Bacillus, natural bacteria, Neisseria gonorrhoeae which attached to the fruit, vegetable and meat. Ozone can also kill hepatitis A, hepatitis B, and other transmitted virus, Beside, it can clean the toxicity of the fruit and vegetable and the detergent residues.
Vegetables chopping,cleaning,air drying production line process: cutting,cleaning and drying.
1. After the artificial separation of raw materials and cutting machine cutting, the conveyor of transfering to QX - 42 bubble cleaning machine. The machine adopts high pressure gas bubble generation, surfing in circulating water pump, ozone antivirus and promote four heavy high pressure water jet cleaning, and set the filter in the device. Filter by MAO roll and roll screen, effective separation of adhesion on the rotten vegetables leaf, food residue and impurities such as hair, impurities by circulating water weir flow, by circulation the sink strainer isolation, in order to maintain the cleanness of clean vegetables. Spray cleaning process and high pressure nozzle for water supply, water supply is adjustable, convenient customer for flexible adjustment according to the vegetable processing and clean degree. At the same time, in this process, customers also can according to oneself circumstance to join the right amount of potions, carry out disinfection again or preservation role.The machine can also be equipped with refrigeration equipment, lower temperature of the material increase the preservation time.
2. waterlogging and drying. After cleaning and disinfection, the material into the drop dryer to remove excess water.
Name:Air bubble cleaning machine
Material: stainless steel
Type:QX-42
Voltage:380V
Power:4KW
Size:4300×930×1480mm
Output:2000-2300kg/h
Remark:The product can be tailor-made according to customer's specific needs
Name:Air drying machine
Material: stainless steel
Voltage:380V
Power:7.1KW
Size:5080×860×1400—1550mm(the height of the machine can be adjusted)
Remark:The product can be tailor-made according to customer's specific needs
Name:Eddy type vegetable washing machine
material:304#
stainless steel type:WL-24
weight:290KG
voltage:380V
power:3.07KW
machine size:3560×1150×1200mm
capacity:1.8Ton/Hour
Remark:the machine can be customed as customer requirment
usage: it is suitable for the leaf vegetable ,root vegetable and the souse vegetable and fruit, such as cabbage ,lettuce,souse carrato etc.
The washing system is consist of three part
1..The main cylinder washing system is advantage of our peer
1. Cyclone flow+bubble washing shenghui Eddy type vegetable washing machine is adopt the advanced washing type: Cyclone flow+bubble washing feature: on the basis of the eddy type vegetable washing machine , we add the bubble design to washing products and the bottom of the tank have add the high pressure air tube, in order to avoid the traditional eddy vegetable washing .to make together phenomenon. But the high pressure air bubble washing can separate the together vegetable . 360 - degree flip five cycles massage type cleaning+16 high voltage adjustable bubble vibration cleaning, domestic initiative double clean wash the whole dish or chopped vegetables, chopped vegetables, sheng hui eddy current type dish washing machine can easily deal with, really achieve multi-usage!
2. No stop block design Internal cylinder body really smooth and round type design, vegetables inside the cylinder body of hydrocyclone cleaning process, only continuous bubble vibration on the surface of vegetables, no prominent in cylinder flow nozzle, avoiding multiple collision damage in the material cleaning, truly to wash vegetables, fruits and vegetables in the process of double protection, avoid a minor injury.
3. Ozone disinfection system Ozone is a broad spectrum of known, efficient, fast, safe, no secondary pollution gas sterilization, buds can kill bacteria, viruses, fungi, and the meat can be damaged bacilli tox
2>. Vibration transmission mechanism
1. The replacement of traditional conveyor belt conveyor, vibrating conveyor structure more simple, 5 times than traditional conveyor belt to reduce cleaning time use more convenient, more frugal artificial.
2. Contact with the material of the transport by punching hole design, effective separation material of ground clutter.
3. Adopt import suspension arm, to ensure continued stability of low frequency vibration in the process of conveying effective drain excess water, ensure material storage time, and provide predewatering function for the dehydration
3>. The secondary filter wedge precision filter,
1. positive 0.3 mm on the back of the 1.5 mm structure, positive filtering fine hair, mi, vegetables, opposite a wash clean, from the traditional planar mesh rinsed repeatedly not clean.The superior design for better filtering, more convenient to clean. Design
2. Automatic filling water, recycling water tank is equipped with automatic filling water device, the cleaning machine system, in addition to cleaning master cylinder of the main inlet, circulating water tank is equipped with vice filling water mouth, deputy hydrating mouth deal primarily with continuous material during the process of cleaning away moisture complement, when the water level to the expected level low, the automatic filling water, without artificial filling water, truly the cleaning process without human intervention. Customers can also be equipped with hair to complete cleaning miscellaneous institutions to assembly line.
Detail of vegetable washing machine /washing machine /wash machine
vegetable washing machine FAQ:
1. What is best method of cleaning and maintenance the tool ?
Answer: Wash with water, can also be appropriate to join detergent to clean it. Tool maintenance: after each tool is cleaned, it should to dry. And then you should coated it with cooking oil to keep the cutting tool lubrication and anti-oxidation.
2. What is the machine maintenance?
Answer: Maintenance methods: machine should be added lubricant on the chain, the gear, bearing every six months, reduction gearbox should add oil. If the machine frequently used, it is recommended that each quarter will be maintenance once a year. If the machine with a belt, conveyor belt, spring, every quarter to check whether is flabby, found relaxation timely adjustment or replacement.
3. If the cutter is blunt, or oxidation with a yellow, how to do?
Answer: If the cutter is blunt, you can grind the knife with grinding wheel or oilstone. If the cutter is oxidation with a yellow, you can use the scouring liquid to scrub, after washing you should add some cooking oil to protect the cutter.
4.How many hours a day the machine can continuously work?
Answer: Generally a machine can 24 hours of uninterrupted work. But we suggest that the machine should stop for a while after work 4-5hours. It has a certain protection on the machine.
5. How to choose and buy vegetable cutter, why the price has a big difference?
Answer: The vegetable cutter can be divided into melon cutting, vegetables cutting and fruit cutting. You can choose according to the material properties and yield. Some vegetable cutter price is high, there are magnetic control protection switch,.The cutting tool is easy to unpick and wash, the cutting effect is good, the blade material is good.
6. what are the advantages of ozone machine of vegetables cutter?
Answer:Ozone is known as a broad-spectrum, efficient, fast, safe, no secondary pollution of the gas sterilization. It can kill bacteria spores, viruses, fungi and can be damaged botulinum toxin. It can exterminate the escherichia coli, staphylococcus aureus, salmonella, aspergillus flavus, fusarium, penicillium, black variant of bacillus, natural bacteria, neisseria gonorrhoeae and so on which attached to the fruits, vegetables, meat and other food . It also can kill the infectious virus, such as hepatitis B and also can remove the pesticide residue in fruits and vegetables and washing product residue toxicity.
7 Why choose shenghui‘s melon cleaning peeling machine?
Answer:( 1).Structure: Is open design, easy to clean up with slag filter or slag boxes(2) The motor and reducer is separation design, to reduce the machine resonance, prolong service life and reducing gear wear and tear.
(3 )The both sides of the bearing is design by fully sealed , put an end to waste into the machine.(4) The material of brush is chosen high toughness bristles to reduce material loss(5)Circuit additional add to a overload protection device.(6)Lateral bearing retainer plate is thickening stainless steel plate, reducing machine vibration.(7)A discharging plate type is binding design, convenient one-handed operation.
Why choose us:
1. 10734 m*m factory area, 12 years experience
2. Warranty date :one year, MOQ: one piece
3. ISO, CE & FDA certificated
4. Fast delivery and good service
5. All of our products have been strictly inspected before shipment.
6. Customers first, satisfying customers forever.
Transactions notes
Trade description:
We provide EXW of product in first quote in most cases, not containing shipping freight and taxes.
After-sales description:
1.Warranty of all product is one year, while consumable items, such as blades, knife tackles, motors and so on are beyond guarantee range
2.We own professional engineering department and maintenance department, providing perfect after-service for customers.
3.We’re always in your service to deal with any problem occurs on machine you purchased from us.
4.Any product sold from our company is attached with a warranty card and a product instruction.
Logistics description:
Products delivered from our factory are required to be packed in standard wooden cases or cartons.
Maintenance:
1.After cleaning the cutters and accessories touching food, don’t forget to dry liquid on surface before you re-assemble them on machine.
2.Lubricate the axis of cutter with edible oil. Dismantle the blunt cutter and polishing it by abrasive stick.
3.Add oil into the reducing gear-box every half a year; lubricate bearings, chains, gears inside machine with oil every quarter.
Attentions:
1.Place machine on the flat ground; trundles of wheeled machine should be locked if there is need to move it.
2.Make sure the feeding mouth equipped on machine should not be blocked by foreign objects,
3.Connect the ground wire and suitable power box based on required voltage described on the labels.
4.Keep hands away from the feeding mouth and outlet of machine when it is operating.
5.Cut power first to stop running machine before dismantling and cleaning the parts.
6.Be careful when dismantling and cleaning the cutter and other sharp part
7.Circuitry part is forbidden to clean.
Trading Flow:
Packing:
Transportation:
Payment and business card:
Shenghui Machinery Co.,Ltd. is located in Dawang High and New Technology Development District, the country-level Hi-tech Development Zone which is in the eatest part of Zhaoqing City, with only 50 kilometers away from Guangzhou City. it only takes 30 minutes by automobile to get to Guangzhou Baiyun Airport. What's more, the 321 national highway and the highway between Guangzhou and Guangxi both have directly exits to the industry zone. So our company has transport facilities.
Our company is a technology one with a collection of research and development, manufacture and selling, mainly concentrates on the designing and manufacturing of aquatic products dealing equipments, meat incision equipments, vegetable washing and shelling equipments. All of them have a complete set of production line.
The main products:
Different kinds of vegetable washing, peeling and cutting single machine equipments.
Fresh meat, cooked meat cutting single machine equipments and production line.
Fish ball production line, including fish flesh deboner, beating machine, meatball forming machine.
From beginning to end, our company insists the operation principle of "High Standard, High Quality, High Efficiency", trying our best to provide customers super quality products, in order to create a win-win situation.
Our company sincerely welcomes customers from all walks of life to guide and conduct business.
About company:
Production processes:
Successful case:
Welcome to visit our factory !! Vegetable washing machine
