Specifications
1)Fireproof Soundproof Fiberglass Ceiling Panel2)non-combustible
3)green building material
4)excellent sound absorption
Fireproof Soundproof Fiberglass Ceiling Panel
The tiles are manufactured from high density fiberglass wool.The visible face has a decorative fiberglass tissue and the back of the tile is covered with normal tissue.The four edges are sealed. The tiles will be parael to the suspended system after installation.
Installation method:
Use exposed grids,grids width:15mm or 24mm
Tiles are easy to trim and install
Both inches and metric grids are available
Main Characteristic OF Fiberglass Ceiling Panel:
Non-combustible
No sagging,wrapping or delaminating
Green building material
Excellent sound absorption
Application OF Fiberglass Ceiling Panel:
Main Specification | National Standard | Main Properties | ||
Surface material |
| 600# | 700# | S101# |
Thickness(mm) |
| 15,20 | 15,20 | 15,20 |
Volume weight(kg/m3) |
| 100 | 100 | 100 |
Noise reduction cofficient | GBJ47-83 | NRC=0.9 | NRC=1.0 | NRC=0.9 |
Level of fireproof | GB8624_1997 | A | A | B1 |
Thermal insulation | JC/T670-2005 | ≥0.40(m2*k)/w | ≥0.40(m2*k)/w | ≥0.40(m2*k)/w |
Thermal insulation | JC/T670-2005 | 0.7mm | 0.7mm | 0.7mm |
Bending destrtorying loading | JC/T670-2005 | ≥40N | ≥40N | ≥40N |
Mipsture rate | JC/T670-2005 | 0.70% | 0.70% | 0.70% |
Size tolerance | JC/T670-2005 | ±1.0mm | ±1.0mm | ±1.0mm |
Limit of redionance | GB/T6566-2001 | lra≤1.3lr≤1.3 | lra≤1.3lr≤1.3 | lra≤1.3lr≤1.3 |
Sniffable particulate matter | GB/T18883-2002 | ≤0.03G/m3 | ≤0.03G/m3 | ≤0.03G/m3 |
Sound Absorption Rating OF Fiberglass Ceiling Panel:
frequency | 125HZ | 250HZ | 500HZ | 1000HZ | 2000HZ | 4000HZ |
NRC | 0.60 | 1.04 | 0.96 | 0.80 | 0.80 | 0.88 |
DESCRIPTION OF FIBERGLASS CEILING PANEL
