automatic carton sealing machine/ juice carton packing machine
- 20 Set / Sets per Month
- Shanghai
- T/T
- high speed metal can vacuum seamer machine
- Factory Automatic Powder Can Seamer/Sealing Machine with Discount
- fish canning machine food cans sealing machine
- milk powder tin sealing machine special-shaped cans sealing machine
- MDcare MD660 LCD Screen Continuous Medical Sealer Dental Cutting 1.2cm width Sterilization Machinery
- MDcare MD386 7'' LCD Touch Screen 77cm length Intellectual Cut-seal-print Complexer
Product Details
Condition: | New | Application: | Commodity | Packaging Type: | Cartons |
Packaging Material: | Paper | Automatic Grade: | Automatic | Driven Type: | Electric |
Power: | 0.6kw | Brand Name: | Leadworld | Model Number: | LW-5050 |
Product Description
Auto carton packing machine is mainly used in sealing and packing cartons, which can be used either independently or as a necessary part of a production line. The machine is widely used in the field of electrical, domestic, textiles, foodstuffs, general merchandise, medicine and chemical industries. The machine can adjust itself to different sizes of cartons. This machine adopts pneumatic method for packaging automatically, it overcomes some disadvantages when adopts manual or semi-auto ones, such as slow speed and the unstable quality. This machine will not damage the surface of packaged objects. The air-jar with every action point adopts AirTAC products, the capability is very stable.
Features:
- Sealing different sizes of cartons without adjustment by human, it will be fit automatically;
- The sealing pressure is adjustable, according to the different materials of cartons;
- The pushing strength of the movement arms on two-side can be regulated according to the weight of cartons;
- Two-side movement arms adjust the objects packaged to the right position automatically;
- The movement frame is driven by double air-jar, smart and smoothly, using long time;
- The 25kg carton can be conveyed steadily by large power convey motor;
- Pneumatic and electric parts combine perfectly, with operation convenient and simple;
- The fine structure and the harmonious color bring pleasure to both the eye and the mind.
Power supply | 220V/380V 50Hz, 600W |
Sealing speed | 15-20bags/min |
Sealing tape | Kraft tap, BOPP tap |
Tape size | 48-72mm |
Carton size | L200-500mm*W200-400mm*H150-400mm |
Operating air source | 6-7kg |
Machine size | 1020*880*1500 |
Machine weight | 200kg |
Main components | 1. Reducer:Chengbang(Taiwan), 2.Contact switch: Omron, 3. Intermediate relay: IDEC, 4. Switch & indicator light: TAYEE, 5. AC contactor:Chint, 6. Cylinder & solenoid valve:SHAKO(Taiwan), 7. Bearing: NSK(Japan), 8. Blade: SKD11(Japan) 9. Belt: imported from Italy, 9. Double brake EDL casters |
