Feature:
1.The machine is mainly used in the beverage filling operations. The three functions of bottle washing, filling and capping are composed in one body of the machine.
2. This 3-in-1 monobloc machine is for fruit juice, tea beverage, etc. Processing.
3. Water bottling machine, it is a fully automatic and multi-functions combined machine, which integrats bottle rinser, filler and screw capper in one unit. It is suitable for filling non carbonated beverage, such as fruit juice, wine, mineral water, pure water and tea.
4. Direct connection technology is used between air conveyor and in-feeding starwheel to substitute in-feeding screw and conveyor. It is easy to change the size of bottles.
5. Neck-hanging technology is applied in bottle transportation. Instead of traditional starwheel, we use neck-hanging gripper to change the size of bottles easily, without adjusting the equipment height. Only arch board and star wheel such little nylon parts need to be changed.
6. The head of filling machine is made of better stainless steel, which is firm and endurable.
The whole juice filling machine has many unique designs. It is the best beverage machine in China at present.
Main technical parameters
Model: (RCGF24-24-8)
Capacity: 4000-10000bph(base on 0.5L bottle)
Filling precision: <5mm (surface location)
PET bottle Specifications: 500ml~1500ml
Bottle neck :20-40,
Bottles height: 130-340mm,
Bottle diameter: 50-100mm;
Apply to the screw-shaped plastic caps(26-35mm)
Bottle washing pressure: 0.16Mpa
Water consumption: 1200kg/h
Air Source pressure: Atmospheric pressure
Air Consumption: 0.3cbm
Total power: 4.27kw
Total weight: 4500kg
Overall dimension: 2780*2200*2350
Main Technical Date:
| Model: | RCGF16-12-6 | RCGF18-18-6 | RCGF24-24-8 | RCGF32-32-10 | RCGF40-40-10 | ||
| capacity :500ml | 4000 | 6000 | 8000 | 12000 | 16000 | ||
| bottle shape: | roud or square | ||||||
| PET bottle: (mm) | (Bottle Diameter):φ50-.φ110mm (Height):150-340mm | ||||||
| cap: | PET screw cap | ||||||
| filling precision: | ≤±5mm | ||||||
| filling pressure:(Mpa) | 0.15-0.35 | 0.15-0.35 | 0.15-0.35 | 0.15-0.35 | 0.15-0.35 | ||
| rinsing pressure:(Mpa) | 0.2-0.25 | 0.2-0.25 | 0.2-0.25 | 0.2-0.25 | 0.2-0.25 | ||
| filling volume :(L) | 0.5 | 3.5 | 4 | 6 | 8 | ||
| overall size:(mm) | 2150*1400 *2050 |
2450*1800 *2350 |
2780*2200 *2350 |
3600*2650 *2350 |
3800*2950 *2400 |
||
| weight: (kg) | 2500 | 3500 | 4500 | 5500 | 6500 | ||
