Lifting Chain Conveyor System

Lifting Chain Conveyor System thumbnail-1
Lifting Chain Conveyor System photo-1
US$ 1,000 - 9,999 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shanghai, China
Brand Name:
Leadworld
Contact Supplier Request Quote Chat Now
Shanghai Leadworld Machinery Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Shanghai, China
Brand Name Leadworld
Model Number LW-CC
Application Other
Voltage 380V
Power(W) 7.5 Kw
Weight 2500kg
Dimension(L*W*H) 3800*600*1500
Certification CE
Warranty one year
After-sales Service Provided Engineers available to service machinery overseas
  • Conveyor System material: SS304

Conveyor System is used for conveying the oil, bottling water ,jucie pr carbonated drink into the machine with high speed,stable performance , good appearance.

  • Chain plate conveyor Functions

Chain conveyor can meet the requirement of single transportation of beverage labelling filling and cleaning equipment.



  • Chain plate material: carbon steel, stainless steel, hot plastic chain etc.
  • Chain plate specifications

Straight chain plate width can be 63.5, 82.5, 101.6, 114.3, 152.4, 190.5, 254, 304.8mm.

Turn chain plate width can be 82.5, 114.3, 152.4, 190.5, 304.8mm.



  • Application

Widely used for automatic transmission, distribution and packaging in food, tin cans, drugs, beverage, cosmetics, cleaning products, paper products, spices, dairy and tobacco.



  • Chain plate conveyor Main technology parameters

◊Chain pitch: 25.4 mm ~203.2 mm

◊Plate chain conveyor width: 200 mm~800 mm (width >800 mm, it can use double plate chains)

◊Transportation speed: 0.4 m ~ 15 m/Min

◊Maximum weight of goods: 800 kg/m2

◊Metal plate chain working environment temperature:-20 °C ~ + 120 °C



  • Notes:according to the needs of your product we can select different width, different shapes of chain plate to complete requirements of flat conveying, flat turning, elevating, dropping.



  • Lifting Chain Conveyor System

Lifting Chain Conveyor SystemLifting Chain Conveyor SystemLifting Chain Conveyor SystemLifting Chain Conveyor SystemLifting Chain Conveyor SystemLifting Chain Conveyor SystemLifting Chain Conveyor System
