Help CenterNew Style Pallet Shrink Wrap Machine
Related Products
-
New Style Pallet Shrink Wrapping MachineUS$ 100 - 9,000MOQ: 1 Set -
New Style Manual Pallet Stretch Wrapping MachineUS$ 100 - 9,000MOQ: 1 Set
-
New Style Pallet Mobile Film Stretch Wrap MachineUS$ 100 - 9,000MOQ: 1 Set
-
New Style Manual Pallet Stretch Wrapper MachineUS$ 100 - 9,000MOQ: 1 Set
-
New Style Manual Pallet Wrap Machine for FilmUS$ 100 - 9,000MOQ: 1 Set
Specifications
mobile pallet wrapping machine1. Programmable control
2. Rotary table recet automatically
Mainly designed for pallet package outside packing with stretch film.
Features:
*Many protection functions,more safe &reliable;
*New design,easy for after-service&maintenance;
*Firm&durable;
*PLC is adopted for electrical control. Can set special wrapping position reinforcement.
Turntable position restored automatically;
*Can set packing types automatically&manual operation also;
*Indicator alarmed automatically;
*Photo electric load height sensing;
Items |
JL2100-J |
JL2100-C |
JL2100-B |
|
Working mode |
Semi-auto |
Auto/Manual |
||
Power voltage |
AC380V/50Hz |
|||
Turntable motor power |
0.40kw |
|||
Up-down motor power |
0.37kw |
|||
Turntable speed |
13r/min(adjustable) |
|||
Film carriage speed |
2.9m/min |
|||
Turntable diameter |
1500mm |
|||
Turntable height |
110mm |
|||
Total weight |
500kg |
530kg |
550kg |
|
Overall dimensions |
L2600mmW1500mmH2650mm |
|||
Tension control |
Mechanical spring |
Magnetic controller |
||
Height control |
manual |
Photocell sensor electric eye |
||
Turntable starting mode |
Soft start & Soft stop |
|||
Max load weight |
2000kg |
|||
Max load height |
2100mm |
|||
Max load size |
L1400mmW1400mmH2100mm |
|||
Special design is available.
