automatic single line soy sauce filling line
- 10 Set / Sets per Month
- Shanghai
- T/T
- Cheapest Automatic Bottle Blowing Machine Prices/factory price automatic bottle shrink wrapping machine
- PET bottle making machine/nice plastic bottle making machine price/high quality plastic bottle blowing machine
- Top quality china automatic machines to make plastic bottles/bottle blowing machinery/Pet Bottles Blowing Machine 750ml
- Chinese PET water bottle blowing machine/equipment / automatic bottle Blowing machinery
- Low price Beverage drinking PET bottle blowing machinery/fully automatic pet bottle blowing machine
- high quality bottle blowing machine/automatic shrink wrapping machine/water bottle blowing machine
Product Details
Condition: | New | Application: | Beverage | Packaging Type: | Bottles |
Packaging Material: | Plastic | Automatic Grade: | Automatic | Driven Type: | Electric |
Place of Origin: | Shanghai, China | Brand Name: | Leadworld | Model Number: | LW-AFM |
Product Description
Specifications
1. High quality2. Stainless steel 304/316L
3. High filling precision
1.The filling machine is used to bottle pure water and mineral water and it is also suiable for liquid material.
2.Pulp filling machine is integrated with washing, filling and capping in one machine. It takes bottle handling technology, which makes changing different size bottle more easily. It can do the bottles from size 200ml to 2000ml. And little spares are need when changing bottles. We suggest users to take same specification bottles, especially the same bottle neck.
3.Our mono-bloc uses high quality stainless steel 304, which makes sure the quality of the producs.
4.The washing we take reversing bottle methods. It has so many washing heads which will spray the inside of the bottle after the bottle is reversed. After washing there will approximate 2 seconds dropping water.
5.Capping we use magnetic capper. And capping power can be adjusted. We equip the machine with "No-bottle, No-Cap" system. If there is no bottle, the caps feeding will be stopped. The capper feeder is stand beside the mono-bloc, which is parallel to the machine.
Model: | LW-XGF12-12-5 | LW-XGF16-12-6 | LW-XGF18-18-6 | LW-XGF24-24-8 | LW-XGF32-32-10 |
capacity (500ml based) | 3000BPH | 4000BPH | 6000BPH | 10000BPH | 12000BPH |
Suitable bottle : | Round bottle or square bottle | ||||
PET bottle: (mm) | (Bottle Diameter):φ50-.φ110mm (Height):150-340mm | ||||
Suitable cap specification | PE screw cap | ||||
filling precision: | ≤±5mm | ||||
filling pressure:(Mpa) | ≤0.4Mpa | ||||
Machine power | 4.4 | 5.2 | 6.2 | 6.8 | 8 |
Machine size:(mm) | 2150*1650*2250 | 2400*1965*2250 | 2680*2200*2250 | 3000*2200*2250 | 3200*2250*2500 |
weight: (kg) | 2800 | 3500 | 4500 | 5500 | 6500 |
